Spiral hose and fittings Parts
























Compare Spiral hose and fittings
Key specifications of the parts listed on this page, taken from the manufacturer's data sheets.
| MPN | A dimension IN | A dimension MM | Hose cut off factor IN | Product length in | Product length mm |
|---|---|---|---|---|---|
| 1B6BF6 | 1.830 | 46.400 | 0.830 | 1.830 | 46.482 |
| 1B32FLG32 | 7.248 | 184.100 | 5.196 | 7.680 | 195.072 |
| 1B32FL32 | 4.650 | 118.100 | 2.600 | 4.650 | 118.110 |
| 1B25EK16 | 3.300 | 83.700 | 1.730 | 2.847 | 72.313 |
| 1B24FLE20 | 5.990 | 152.100 | 4.440 | 7.173 | 182.200 |
| 1B24FLD20 | 6.129 | 155.700 | 4.582 | 6.129 | 155.700 |
| 1B24BF24 | 4.640 | 117.900 | 1.570 | 3.149 | 79.984 |
| 1B24 | 2.126 | 54.000 | — | 2.216 | 54.000 |
| 1B20FLF20 | 5.300 | 134.700 | 3.760 | 5.490 | 139.446 |
| 1B20FLD20 | 5.380 | 136.700 | 3.830 | 5.570 | 141.478 |
| 1B20FLA16 | 4.790 | 121.600 | 3.460 | 4.810 | 122.174 |
| 1B20FL16 | 3.770 | 95.800 | 2.440 | 3.770 | 95.758 |
| 1B20FH20 | 4.060 | 103.100 | 2.510 | 4.060 | 103.124 |
| 1B20EK12 | 3.090 | 78.600 | 1.670 | 2.579 | 65.506 |
| 1B20BT20 | 4.660 | 118.400 | 2.490 | 4.660 | 118.400 |
| 1B20 | 1.910 | 48.500 | — | 1.910 | 48.514 |
| 1B16FLF16 | 4.550 | 115.500 | 3.220 | 4.550 | 115.570 |
| 1B16FLE16 | 5.000 | 127.100 | 3.670 | 5.000 | 127.000 |
| 1B16FLE12 | 5.790 | 147.000 | 4.360 | 4.720 | 119.888 |
| 1B16FLB20 | 4.476 | 113.700 | 2.929 | 4.470 | 113.538 |
| 1B16FLA12 | 4.040 | 102.600 | 2.970 | 4.040 | 102.616 |
| 1B16FL20 | 4.350 | 110.500 | 2.180 | 3.760 | 95.504 |
| 1B16FH12 | 3.190 | 81.000 | 2.120 | 3.310 | 84.074 |
| 1B16 | 1.626 | 41.300 | — | 1.626 | 41.300 |
Common to all listed parts
| Construction Style | Crimp |
| Product material | Carbon steel |
| Series | B Series |
| Thread sealant | No |
| Working temperature min C | -40 |
| Working temperature min F | -40 |
