Danfoss 1B16FLE16

HOSE NIPPLE ASSY,4S/16,C61/16,CS,67.5D

MPN
1B16FLE16
Price and lead time confirmed within 1 business day
Request a Quote
  1. 1We check stock, condition and lead time
  2. 2You get a written quote by email
  3. 3Approve it and we ship — in-stock parts within 1 business day

A real person replies, typically within 1 business day — see our privacy policy.

  • 12-month warranty (new) · 3-month (used/refurbished)
  • 30-day returns, no restocking fee on unused parts
  • 100% positive eBay feedback
  • Ships via

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss 1B16FLE16?

Danfoss HOSE NIPPLE ASSY,4S/16,C61/16,CS,67.5D, manufacturer part number 1B16FLE16. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

Specifications

EAN/UPC678146129109
A dimension IN5.000
A dimension MM127.100
Angle shape67.5 Degree
BrandAeroquip by Danfoss
Compatible hose ID IN1.000
Compatible hose ID MM25.400
Compatible hosesFC659, FC736, GH493, FC636
Construction StyleCrimp
Drop dimension IN1.740
Drop dimension MM44.1
End size 1-16
End type 1Split flange code 61
Finish platingZinc plating
Hose cut off factor IN3.670
Hose cut off factor MM93.300
Hose size-16
Inside diameter IN0.7800
Inside diameter MM19.9000
Product height in1.740
Product height mm44.196
Product length in5.000
Product length mm127.000
Product materialCarbon steel
Product width in2.081
Product width mm52.857 mm
SeriesB Series
Thread sealantNo
Working pressure max BAR345.00
Working pressure max PSI5000.00
Working temperature max C121
Working temperature max F250
Working temperature min C-40
Working temperature min F-40

1B16FLE16: frequently asked questions

When can 1B16FLE16 be shipped?

1B16FLE16 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up 1B16FLE16 in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for 1B16FLE16 and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 1B16FLE16, subject to availability and destination.
