Material number: X20CP1584 Description: Intel Atom 600 MHz processor with an additional I/O processor Onboard Ethernet, POWERLINK with poll response chaining and USB 1 slot for modular interface expansion CompactFlash as removable application memory 256 MB DDR2-SDRAM Fanless The controller is based on an Atom processor clocked at 0.6 GHz and equipped with 256 MB DDR2 SDRAM. USB, Ethernet, POWERLINK and removable CompactFlash are all included as standard features. A Gigabit Ethernet interface is a standard feature. For even more real-time network performance, the onboard POWERLINK interface supports poll response chaining mode (PRC). The controller is equipped with one slot available for X20 communication modules. Various bus and network systems can easily be integrated into the X20 system through the use of communication modules.

Material number: X20CP1586 Description: Intel Atom 1.6 GHz processor with an additional I/O processor Onboard Ethernet, POWERLINK with poll response chaining and USB 1 slot for modular interface expansion CompactFlash as removable application memory 512 MB DDR2 SDRAM Fanless The X20CP1586 is a powerful controller for the X20 system. This controller is especially useful for applications that require short cycle times, have to process very large amounts of data or carry out floating point operations. It is clocked at 1.6 GHz and equipped with 512 MB DDR2 SDRAM. USB, Ethernet, POWERLINK and removable CompactFlash are all included as standard features. The standard Ethernet interface is capable of handling communication in the gigabit range. For even more real-time network performance, the onboard POWERLINK interface supports poll response chaining mode (PRC). The controller is equipped with one slot available for X20 communication modules. Various bus and network systems can easily be integrated into the X20 system through the use of communication modules.

Material number: X20CP1584 Description: Intel Atom 600 MHz processor with an additional I/O processor Onboard Ethernet, POWERLINK with poll response chaining and USB 1 slot for modular interface expansion CompactFlash as removable application memory 256 MB DDR2-SDRAM Fanless The controller is based on an Atom processor clocked at 0.6 GHz and equipped with 256 MB DDR2 SDRAM. USB, Ethernet, POWERLINK and removable CompactFlash are all included as standard features. A Gigabit Ethernet interface is a standard feature. For even more real-time network performance, the onboard POWERLINK interface supports poll response chaining mode (PRC). The controller is equipped with one slot available for X20 communication modules. Various bus and network systems can easily be integrated into the X20 system through the use of communication modules.

X20CP3686X B&R X20 CP 3686X X20 PLC Intel Atom 1.3 GHz performance with integrated I/O processor 1x RS232 1x Ethernet 1x POWERLINK (V2) 2x USB 1x X2X Link/X2X+

X20CP3685 B&R Controller PLC Intel Atom 800 MHz performance with integrated I/O processor 1x RS232 1x Ethernet 1x POWERLINK (V2) 2x USB 1x X2X Link

X20CP1584 New Without Box B&R

X20CP0292 New B&R

X20CP0201

Compact CPU Module
