Braided hose and fittings Parts
Compare Braided hose and fittings
Key specifications of the parts listed on this page, taken from the manufacturer's data sheets.
| MPN | A dimension IN | A dimension MM | Hose cut off factor MM | Product length in | Product length mm |
|---|---|---|---|---|---|
| 1G40DLB24 | 5.980 | 152.000 | 105.700 | 7.160 | 181.864 |
| 1G40DLA24TY | 6.980 | 177.400 | 131.200 | 8.160 | 207.264 |
| 1G40DL24TY | 3.430 | 87.200 | 40.900 | 3.433 | 87.201 |
| 1G40DL24 | 3.430 | 87.200 | 40.900 | 3.433 | 87.198 |
| 1G32FLB32 | 7.540 | 191.600 | 137.500 | 8.940 | 227.076 |
| 1G32FLB24 | 7.000 | 177.900 | 138.000 | 8.670 | 220.218 |
| 1G32FLA24 | 6.070 | 154.200 | 107.900 | 6.707 | 170.358 |
| 1G32FL32 | 4.680 | 118.900 | 64.800 | 4.681 | 118.897 |
| 1G32FL24 | 4.170 | 106.000 | 65.532 | 4.400 | 111.760 |
| 1G32DLB20 | 5.110 | 130.000 | 86.000 | 5.118 | 129.997 |
| 1G32DLA20 | 5.820 | 148.000 | 104.000 | 6.811 | 172.999 |
| 1G32DL20 | 3.290 | 83.700 | 39.700 | 3.295 | 83.701 |
| 1G32DK20 | 3.120 | 79.400 | 35.400 | 3.126 | 79.400 |
| 1G25EK16 | 2.850 | 72.300 | 37.900 | 2.850 | 72.390 |
| 1G25DS16 | 3.900 | 78.500 | 44.100 | 1.909 | 48.489 |
| 1G25DLB16 | 3.940 | 100.000 | 65.600 | 4.744 | 120.500 |
| 1G25DLA16 | 4.060 | 103.100 | 68.700 | 4.900 | 124.460 |
| 1G25DL16 | 2.680 | 68.200 | 33.800 | 2.685 | 68.199 |
| 1G25DK16 | 2.600 | 66.000 | 31.600 | 2.600 | 66.040 |
| 1G25AD16 | 2.590 | 65.800 | 31.400 | 2.591 | 65.801 |
| 1G24FRB24 | 4.380 | 111.300 | 71.374 | 5.560 | 141.224 |
| 1G24FR24 | 3.950 | 100.300 | 60.452 | 4.780 | 121.412 |
| 1G24FLB32 | 6.450 | 163.800 | 109.700 | 7.635 | 193.929 |
| 1G24FLB24TY | 6.180 | 156.900 | 110.600 | 7.370 | 187.198 |
Common to all listed parts
| Construction Style | Crimp |
| Product material | Carbon steel |
| Series | OTC |
| Working temperature max C | 150 |
| Working temperature max F | 302 |
| Working temperature min C | -40 |
| Working temperature min F | -40 |
