B&R 5MP050.0653-04
Request a Quote
Quick facts
| Availability | Confirmed on request |
| Lifecycle | active |
| Warranty | 12-month (new) · 3-month (used/refurbished) |
| Weight | 0.13 kg |
Shipping & availability
When can 5MP050.0653-04 be shipped?
5MP050.0653-04 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.
Can I pick up 5MP050.0653-04 in person?
Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.
Is express delivery available?
Yes — mention it when you request a quote for 5MP050.0653-04 and we'll include express shipping options in our reply.
My factory is down and I need this urgently — can you help?
For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 5MP050.0653-04, subject to availability and destination.
6.5" VGA TFT color displayAnalog resistive touch screenIntel PXA 270 processor31 system keys and soft keysStop buttonHandwheelKey switch2 integrated 3-position enable switches Mobile Panel MP50, 6.5" VGA TFT color display with touch screen (analog resistive), Intel PXA 270 processor, 256 MB DRAM, 128 MB flash memory, ETH 10/100, USB 1.1, 31 system keys, stop button, handwheel, key switch, 2 integrated 3-position enable switches, handle. Delivered as an assembly (order cables and operating system separately).
Specifications
Specifications
| Reset button | Yes |
| CE | Yes |
| KC | Yes |
| Type | USB 1.1 |
| Clock frequency | 416 MHz |
| Mode/Node switches | No |
| Controller | SMSC11X |
| Size | - |
| Battery-backed | - |
| Diagonal | 6.5" (165 mm) |
| Colors | 65,535 |
| Resolution | VGA, 640 x 480 pixels |
| Contrast | 300:1 |
| Horizontal | Direction R / Direction L = 55° |
| Vertical | Direction U = 30° / Direction D = 60° |
| Brightness | 500 cd/m² |
| Half-brightness time | 100,000 h |
| Technology | Analog, resistive |
| Quantity | 1 |
| Variant | Shielded RJ45 port |
| Transfer rate | 10/100 Mbit/s |
| Current-carrying capacity | Max. 500 mA |
| Max. baud rate | 100 Mbit/s |
| Function keys | No |
| Soft keys | 9 |
| System keys | 22 |
| 3-axis joystick | No |
| Electronic handwheel | Yes |
| Illuminated pushbutton | No |
| Stop button | Yes (2 normally closed contacts, right position) |
| Enable switch | Yes (2 3-position buttons, left and right position) |
| Override potentiometer | No |
| Key switch | Yes |
| LEDs | 4 |
| Nominal voltage | 24 VDC ±25% (integrated reverse polarity protection) |
| Inrush current | Max. 5.6 A (current limiting available) |
| Power consumption | 9.6 W (400 mA at 24 VDC) |
| Max. interruption of power supply | ≤10 ms |
| Galvanic isolation | No |
| Drop height | 1.5 m to industrial floor |
| Flame-retardant | UL94V-0 |
| Degree of protection per EN 60529 | IP65 |
| Protection class | Class 3 per EN 61131-2 or EN 50178 |
| Operation | Max. 3000 m |
| Storage | Max. 95%, non-condensing |
| Transport | Max. 95%, non-condensing |
| Material | Polyester |
| Coating | Similar to RAL 7011 |
| Width | 252 mm |
| Height | 114 mm |
| Depth | 240 mm |
| Weight | Approx. 1250 g |
