Braided hose and fittings Parts

Danfoss

20591Y-36-12TZ

HOSE NIPPLE ASSY,1P/12,DKOH-B/36,CS,90D

Danfoss

20591Y-36-12EQSVT

HOSE NIPPLE ASSY,1P/12,DKOH-B/36,AP,90D

Danfoss

20591Y-30-10TZ

HOSE NIPPLE ASSY,1P/10,DKOH-B/30,CS,90D

Danfoss

20591Y-30-08EQSVT

HOSE NIPPLE ASSY,1P/08,DKOH-B/30,AP,90D

Danfoss

20591Y-24-08TZ

HOSE NIPPLE ASSY,1P/08,DKOH-B/24,CS,90D

Danfoss

20591Y-20-06TZ

HOSE NIPPLE ASSY,1P/06,DKOH-B/20,CS,90D

Danfoss

20591Y-18-06TZ

HOSE NIPPLE ASSY,1P/06,DKOH-B/18,CS,90D

Danfoss

20591Y-18-04SRT

HOSE NIPPLE ASSY,1P/04,DKOH-B/18,AN,90D

Danfoss

20591Y-16-06WZ

HOSE NIPPLE ASSY,1P/06,DKOH-B/16,CS,90D

Danfoss

20591Y-16-05WZ

HOSE NIPPLE ASSY,1P/05,DKOH-B/16,CS,90D

Danfoss

20591Y-16-04TZ

HOSE NIPPLE ASSY,1P/04,DKOH-B/16,CS,90D

Danfoss

20591EQY-24-08SVT

HOSE NIPPLE ASSY,1P/08,DKOH-B/24,AP,90D

Danfoss

20591-52-20TZ

HOSE NIPPLE ASSY,2P/20,DKOH-B/52,CS,90D

Danfoss

20591-42-20WZ

HOSE NIPPLE ASSY,2P/20,DKOH-B/42,CS,90D

Danfoss

20591-42-16TZF

HOSE NIPPLE ASSY,2P/16,DKOH-B/42,CS,90D

Danfoss

20591-36-16H90WZ

HOSE NIPPLE ASSY,2P/16,DKOH-B/36,CS,90D

Danfoss

20591-36-12SRT

HOSE NIPPLE ASSY,2P/12,DKOH-B/36,AN,90D

Danfoss

20591-30-12SRT

HOSE NIPPLE ASSY,2P/12,DKOH-B/30,AN,90D

Danfoss

20591-30-10TZF

HOSE NIPPLE ASSY,2P/10,DKOH-B/30,CS,90D

Danfoss

20591-30-08TZ

HOSE NIPPLE ASSY,2P/08,DKOH-B/30,CS,90D

Danfoss

20591-24-10WZ

HOSE NIPPLE ASSY,2P/10,DKOH-B/24,CS,90D

Danfoss

20591-24-06TZ

HOSE NIPPLE ASSY,2P/06,DKOH-B/24,CS,90D

Danfoss

20591-22-08TZ

HOSE NIPPLE ASSY,2P/08,DKOH-B/22,CS,90D

Danfoss

20591-22-06TZF

HOSE NIPPLE ASSY,2P/06,DKOH-B/22,CS,90D

Compare Braided hose and fittings

Key specifications of the parts listed on this page, taken from the manufacturer's data sheets.

MPN	Drop dimension IN	Product height in	Product height mm	Product length in	Product length mm
20591Y-36-12TZ	2.322	2.449	62.200	3.720	94.500
20591Y-36-12EQSVT	2.322	3.226	81.940	5.007	127.178
20591Y-30-10TZ	1.948	2.480	62.992	4.252	108.001
20591Y-30-08EQSVT	1.811	2.515	63.881	3.622	91.998
20591Y-24-08TZ	1.692	2.185	55.499	3.386	86.004
20591Y-20-06TZ	1.397	1.791	45.491	3.012	76.504
20591Y-18-06TZ	1.377	1.703	43.256	3.071	78.003
20591Y-18-04SRT	1.259	1.767	44.900	2.716	69.000
20591Y-16-06WZ	1.218	1.830	46.482	2.790	70.866
20591Y-16-05WZ	1.218	1.555	39.497	2.657	67.487
20591Y-16-04TZ	1.218	1.506	38.252	2.657	67.487
20591EQY-24-08SVT	1.692	2.417	61.391	3.444	87.477
20591-52-20TZ	3.405	4.370	110.998	6.969	177.013
20591-42-20WZ	3.444	4.350	110.490	6.713	170.510
20591-42-16TZF	2.755	3.543	89.992	5.906	150.012
20591-36-16H90WZ	2.500	3.540	90.000	4.400	112.000
20591-36-12SRT	2.322	3.180	80.772	4.920	124.968
20591-30-12SRT	2.145	2.720	69.088	4.421	112.293
20591-30-10TZF	1.948	2.480	62.992	4.252	108.001
20591-30-08TZ	1.811	2.303	58.496	3.701	94.005
20591-24-10WZ	1.791	2.220	56.388	3.700	93.980
20591-24-06TZ	1.437	1.870	47.498	3.130	79.502
20591-22-08TZ	1.673	2.116	53.746	3.425	86.995
20591-22-06TZF	1.417	1.831	46.507	3.071	78.003

Common to all listed parts

Angle shape	90 Degree
Construction Style	Crimp
End Type 1	24 deg. DKO swivel heavy duty
Working temperature min C	-40
Working temperature min F	-40
