Schneider Electric TSXDEZ32D2 – TSX Micro - 32 Discret Input DC
Discontinued by Schneider Electric — we can still source the original TSXDEZ32D2 (new, used or refurbished, subject to availability). Request a quote below.
Request a Quote
Quick facts
| Availability | Confirmed on request |
| Category | Modicon TSX Micro |
| Lifecycle | Discontinued |
| Warranty | 12-month (new) · 3-month (used/refurbished) |
| Country of origin | FR |
| UPC / EAN | 3389110738056 |
| Datasheet | Manufacturer datasheet ↗ |
Shipping & availability
Can I still buy the TSXDEZ32D2 now that it is discontinued?
Yes. Schneider Electric has discontinued the TSXDEZ32D2, but sourcing discontinued parts is what PartnerPLC specialises in — new old stock, used and refurbished units. Request a quote and we'll confirm availability, condition and lead time.
When can TSXDEZ32D2 be shipped?
TSXDEZ32D2 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.
Can I pick up TSXDEZ32D2 in person?
Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.
Is express delivery available?
Yes — mention it when you request a quote for TSXDEZ32D2 and we'll include express shipping options in our reply.
My factory is down and I need this urgently — can you help?
For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for TSXDEZ32D2, subject to availability and destination.
This product is part of the Modicon TSX Micro range, an offer of Programmable Logic Controllers (PLC). This discrete input module has 32 screw terminal block resistive inputs. It is an input module with a rated supply voltage of 24V DC, a positive current consumption of 254mA and an isolation voltage of 1500V AC. Input is compatible with 2/3-wire proximity sensors PNP/NPN. It is suitable for infrastructures, machine and manufacturing control applications. It meets IEC 1131-2 Type 2 standards. The automation platform designed to enhance system's performance. With Micro's accuracy, flexibility and increased productivity, you have a real partner at the heart of the machine. Discontinued by Schneider Electric. PartnerPLC sources discontinued and surplus Schneider Electric automation parts — request a quote for price, condition and lead time.
Specifications
Main
| Range of product | Modicon TSX Micro automation platform |
| Product or component type | Discrete input module |
| Discrete input number | 32 screw terminal block |
| Discrete input voltage | 24 V DC, discrete input logic: positive or negative; 19...30 V |
| Discrete input current | 7 mA |
| Input voltage limits | >= 11 V at state 1; < 5 V at state 0 |
| Current state 0 guaranteed | <= 2 mA |
| Current state 1 guaranteed | >= 6 mA |
| Input impedance | 3.4 Ohm |
| Response time | 0.1...7.5 ms at state 0 to state 1; 0.1...7.5 ms at state 1 to state 0 |
Complementary
| Standards | IEC 1131-2 Type 2 |
| Input compatibility | 2/3-wire proximity sensors PNP/NPN |
| Discrete input type | Current sink |
| Current consumption | 254 mA positive |
| Isolation voltage | 1500 V AC 1 s |
Downloads & documentation
Official documents from Schneider Electric, downloaded directly from the manufacturer.
Data sheets & manuals
| Product data sheet TSXDEZ32D2 |
