Schneider Electric TSXDEZ12D2K – TSX Micro - 12 Discret Input DC
Discontinued by Schneider Electric — we can still source the original TSXDEZ12D2K (new, used or refurbished, subject to availability). Request a quote below.
Request a Quote
Quick facts
| Availability | Confirmed on request |
| Category | Modicon TSX Micro |
| Lifecycle | Discontinued |
| Warranty | 12-month (new) · 3-month (used/refurbished) |
| Country of origin | FR |
| UPC / EAN | 3389110540437 |
| Datasheet | Manufacturer datasheet ↗ |
Shipping & availability
Can I still buy the TSXDEZ12D2K now that it is discontinued?
Yes. Schneider Electric has discontinued the TSXDEZ12D2K, but sourcing discontinued parts is what PartnerPLC specialises in — new old stock, used and refurbished units. Request a quote and we'll confirm availability, condition and lead time.
When can TSXDEZ12D2K be shipped?
TSXDEZ12D2K is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.
Can I pick up TSXDEZ12D2K in person?
Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.
Is express delivery available?
Yes — mention it when you request a quote for TSXDEZ12D2K and we'll include express shipping options in our reply.
My factory is down and I need this urgently — can you help?
For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for TSXDEZ12D2K, subject to availability and destination.
Schneider Electric TSXDEZ12D2K — TSX Micro - 12 Discret Input DC (Modicon TSX Micro). Discontinued by Schneider Electric. PartnerPLC sources discontinued and surplus Schneider Electric automation parts — request a quote for price, condition and lead time.
Specifications
Main
| Range of product | Modicon TSX Micro automation platform |
| Product or component type | Discrete input module |
| Discrete input number | 12 1 HE-10 connector |
| Discrete input voltage | 24 V DC, discrete input logic: positive; 19...30 V |
| Discrete input current | 7 mA |
| Input voltage limits | >= 11 V at state 1; < 5 V at state 0 |
| Current state 0 guaranteed | <= 2 mA |
| Current state 1 guaranteed | >= 6 mA |
| Input impedance | 3.4 Ohm |
| Response time | 0.1...7.5 ms at state 0 to state 1; 0.1...7.5 ms at state 1 to state 0 |
Complementary
| Standards | IEC 1131-2 Type 2 |
| Input compatibility | 2/3-wire proximity sensors PNP/NPN |
| Discrete input type | Current sink |
| Current consumption | 104 mA positive |
| Isolation voltage | 1500 V AC 1 s |
Environment
| Net weight | 0.16 kg |
Downloads & documentation
Official documents from Schneider Electric, downloaded directly from the manufacturer.
Data sheets & manuals
| Product data sheet TSXDEZ12D2K |
