Schneider Electric TSXDEZ12D2 – TSX Micro - 12 Discret Input DC

Name: Schneider Electric TSXDEZ12D2 – TSX Micro - 12 Discret Input DC
Brand: Schneider Electric
SKU: TSXDEZ12D2

MPN: TSXDEZ12D2 · Brand: Schneider Electric

Price on request

Discontinued by Schneider Electric — we can still source the original TSXDEZ12D2 (new, used or refurbished, subject to availability). Request a quote below.

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)

30-day returns, no restocking fee on unused parts

Ships via

Quick facts

Availability	Confirmed on request
Category	Modicon TSX Micro
Lifecycle	Discontinued
Warranty	12-month (new) · 3-month (used/refurbished)
Country of origin	FR
UPC / EAN	3389110540420
Datasheet	Manufacturer datasheet ↗

Shipping & availability

Can I still buy the TSXDEZ12D2 now that it is discontinued?

Yes. Schneider Electric has discontinued the TSXDEZ12D2, but sourcing discontinued parts is what PartnerPLC specialises in — new old stock, used and refurbished units. Request a quote and we'll confirm availability, condition and lead time.

When can TSXDEZ12D2 be shipped?

TSXDEZ12D2 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up TSXDEZ12D2 in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for TSXDEZ12D2 and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for TSXDEZ12D2, subject to availability and destination.

This product is part of the Modicon TSX Micro range, an offer of Programmable Logic Controllers (PLC). This discrete input module has 32 screw terminal block resistive inputs. It is an input module with a rated supply voltage of 24V DC, a positive current consumption of 123mA, a negative current consumption of 107mA and an isolation voltage of 1500V AC. Input is compatible with 2/3-wire proximity sensors PNP/NPN. It weighs 0.23kg. It is suitable for infrastructures, machine and manufacturing control applications. It meets IEC 1131-2 Type 1 standards. The automation platform designed to enhance system's performance. With Micro's accuracy, flexibility and increased productivity, you have a real partner at the heart of the machine. Discontinued by Schneider Electric. PartnerPLC sources discontinued and surplus Schneider Electric automation parts — request a quote for price, condition and lead time.

Specifications

Main

Range of product	Modicon TSX Micro automation platform
Product or component type	Discrete input module
Discrete input number	12 screw terminal block
Discrete input voltage	24 V DC, discrete input logic: positive or negative; 19...30 V
Discrete input current	9 mA
Input voltage limits	>= 11 V at state 1; < 5 V at state 0
Current state 0 guaranteed	<= 1.5 mA
Current state 1 guaranteed	>= 2.5 mA
Input impedance	2.4 Ohm
Response time	0.1...7.5 ms at state 0 to state 1; 0.1...7.5 ms at state 1 to state 0

Complementary

Standards	IEC 1131-2 Type 1
Input compatibility	2/3-wire proximity sensors PNP/NPN
Discrete input type	Resistive
Current consumption	123 mA positive; 107 mA negative
Isolation voltage	1500 V AC 1 s
