Mitsubishi Electric EMU4-HD1A-MB
Mitsubishi Energy measuring EcoMonitorLight
- MPN
- EMU4-HD1A-MB
Request a Quote
- 1We check stock, condition and lead time
- 2You get a written quote by email
- 3Approve it and we ship — in-stock parts within 1 business day
- 12-month warranty (new) · 3-month (used/refurbished)
- 30-day returns, no restocking fee on unused parts
- 100% positive eBay feedback
- Ships via
Have spare Mitsubishi Electric (Factory Automation) parts? We buy surplus →
What is the Mitsubishi Electric EMU4-HD1A-MB?
The Mitsubishi Electric EMU4-HD1A-MB is a ecoMonitorLight in the Energy measuring. MODBUS RTU (RS-485) communication. Specifications and manuals below are Mitsubishi Electric's own data.
Specifications
Product
| Series | Energy measuring |
| Category | EcoMonitorLight |
| Type | High Performance Model |
| Outline | MODBUS RTU (RS-485) communication |
Specifications
| Category | Energy Saving Supporting Devices |
| Group | Energy Measuring Unit |
| Model | EcoMonitorLight |
| Use | High Performance Model |
| Model name | EMU4-HD1A-MB |
| Transmission | MODBUS RTU (RS-485) communication |
| Phase wire system | Single-phase 2-wire, single-phase 3-wire, 3-phase 3-wire, 3-phase 4-wire |
| Instrument ratings: Voltage circuit: Single-phase 2-wire 3-phase 3-wire | 110V, 220V, 440V AC common |
| Instrument ratings: Voltage circuit: Single-phase 3-wire | 110V AC (Between 1 and 2 line, 2 and 3 line), 220V AC (Between 1 and 3 line), 220V AC (Between 1 and 2 line, 2 and 3 line), 440V AC (Between 1 and 3 line) |
| Instrument ratings: Voltage circuit: 3-phase 4-wire | Minimum: 63.5V/110V AC, Maximum: 277V/480V AC |
| Instrument ratings: Current circuit | 5A, 50A, 100A, 250A, 400A, 600A AC * Each value refers to the split type current at the primary side of the current sensor. |
| Instrument ratings: Frequency | 50Hz / 60Hz (Auto-detect) |
| Auxiliary power rating | 100V-240V AC (+10%, -15%) 50Hz/60Hz |
| No. of measurement circuits | 1 circuit |
| Measurement items | current, current demand, voltage, power, power demand, reactive power, power factor, frequency, electric energy (consumption, regenerative), reactive electric energy, apparent power, harmonic current, harmonic voltage, number of alarm exceedance, band monitoring lost rate, pulse count, periodic electric energy, electric energy conversion value, pulse conversion vaue |
| Data update cycle | 250msec |
| External input specification | 1 input (pulse input, contact input) |
| External output specification | 1 output (pulse output, contact output, digital output) |
| Power interruption backup | stored in nonvolatile memory (setting, accumulated value, operating time) |
| Compatible standard | UL: UL61010-1, CE Marking / UKCA Marking (EMC: EN 61326-1, LVD: EN 61010-1) |
| Weight | 0.25kg |
| External dimensions (unit: mm) | 75 (W) x 90 (H) x 75 (D) (Except for the protruding portions) (Maximum dimension including the protruding portions: 79 (W) x 90 (H) x 75 (D)) |
No matching specifications
Downloads & documentation
Official documents from Mitsubishi Electric (Factory Automation), downloaded directly from the manufacturer.
Data sheets & manuals
- Energy Measuring Unit (EcoMonitorLight) Before using the instrument (MODEL:EMU4-BD1A-MB/EMU4-HD1A-MB) (IB63G63E-B)
- Energy Measuring Unit (EcoMonitorLight) User's Manual (MODEL:EMU4-BD1A-MB/EMU4-HD1A-MB) (IB63G65-C)
- Energy Measuring Unit Programming Manual (CC-Link) For ver.1 remote device station (EcoMonitorPro/EMU3/EcoMonitorLight/EcoMonitorPlus Series) (LEN160305-C)
- Energy Measuring Unit Programming Manual (CC-Link) For ver.2 remote device station (MODEL:EMU4-BD1-MB/EMU4-HD1-MB/EMU4-BM1-MB/EMU4-HM1-MB/EMU4-LG1-MB/EMU4-A2/EMU4-VA2/EMU4-AX4/EMU4-PX4) (LEN160316-C)
- Energy Measuring Unit Programming Manual (CC-Link IE Field Network Basic) (SLMP) (MODEL:EMU4-BD1-MB/EMU4-HD1-MB/EMU4-FD1-MB/EMU4-BM1-MB/EMU4-HM1-MB/EMU4-LG1-MB/EMU4-A2/EMU4-VA2/EMU4-AX4/EMU4-PX4) (LEN
- Energy Measuring Unit Programming Manual (CC-Link IE TSN) (SLMP) (MODEL:EMU4-BD1A-MB/EMU4-HD1A-MB/EMU4-FD1-MB/EMU4-BM1-MB/EMU4-HM1-MB/EMU4-LG1-MB/EMU4-CNT-MB/EMU4-A2/EMU4-VA2/EMU4-AX4/EMU4-PX4) (LEN21
- Energy Measuring Unit EcoMonitorLight/EcoMonitorPlus Series MODBUS I/F Specification (MODEL:EMU4-BD1-MB/EMU4-HD1-MB/EMU4-BM1-MB/EMU4-HM1-MB/EMU4-LG1-MB/EMU4-CNT-MB/EMU4-A2/EMU4-VA2/EMU4-PX4/EMU4-AX4)
EMU4-HD1A-MB: frequently asked questions
When can EMU4-HD1A-MB be shipped?
EMU4-HD1A-MB is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.
Can I pick up EMU4-HD1A-MB in person?
Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.
Is express delivery available?
Yes — mention it when you request a quote for EMU4-HD1A-MB and we'll include express shipping options in our reply.
My factory is down and I need this urgently — can you help?
For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for EMU4-HD1A-MB, subject to availability and destination.
