Mitsubishi Electric EMU4-FD1-MB

Mitsubishi Energy measuring EcoMonitorLight

MPN
EMU4-FD1-MB
Price and lead time confirmed within 1 business day
Request a Quote
  1. 1We check stock, condition and lead time
  2. 2You get a written quote by email
  3. 3Approve it and we ship — in-stock parts within 1 business day

A real person replies, typically within 1 business day — see our privacy policy.

  • 12-month warranty (new) · 3-month (used/refurbished)
  • 30-day returns, no restocking fee on unused parts
  • 100% positive eBay feedback
  • Ships via

Have spare Mitsubishi Electric (Factory Automation) parts? We buy surplus →

What is the Mitsubishi Electric EMU4-FD1-MB?

The Mitsubishi Electric EMU4-FD1-MB is a ecoMonitorLight in the Energy measuring. MODBUS RTU (RS-485) communication. Specifications and manuals below are Mitsubishi Electric's own data.

Specifications

Product

SeriesEnergy measuring
CategoryEcoMonitorLight
TypeGeneral Current Transformer Model
OutlineMODBUS RTU (RS-485) communication

Specifications

CategoryEnergy Saving Supporting Devices
GroupEnergy Measuring Unit
ModelEcoMonitorLight
UseGeneral Current Transformer Model
Model nameEMU4-FD1-MB
TransmissionMODBUS RTU (RS-485) communication
Phase wire systemSingle-phase 2-wire, single-phase 3-wire, 3-phase 3-wire, 3-phase 4-wire common
Instrument ratings: Voltage circuit: Single-phase 2-wire 3-phase 3-wire110V, 220V, 440V AC common
Instrument ratings: Voltage circuit: Single-phase 3-wire110V AC (between wires 1 and 2, and wires 2 and 3), 220V AC (between wires 1 and 3)
Instrument ratings: Voltage circuit: 3-phase 4-wireMinimum: 63.5V/110V AC, Maximum: 277V/480V AC
Instrument ratings: Current circuit50A, 100A, 250A, 400A, 600A (Dedicated split-type current sensor is used. All values indicate primary current values of current sensor.) 5A(Dedicated 5A current sensor is used. Current transformer (CT) is used in two-step configuration together with the 5A current sensor in order to allow a maximum primary current value setting of 6,000A)
Instrument ratings: Frequency50-60Hz (automatic frequency selection)
Auxiliary power rating100V-240V AC (+10%, -15%) 50Hz/60Hz
No. of measurement circuits1 circuit
Consumption VA: Voltage circuitFor each phase: 0.1VA (110V AC), 0.2VA (220V AC), 0.4VA (440V AC)
Consumption VA: Auxiliary power circuit110V AC: 9VA, 220V AC: 10VA
Measurement itemsCurrent, demanded current, voltage, power, demanded power, reactive power, power factor, frequency, electric energy (regenerative, consumption), reactive electric energy, operating time, apparent power, harmonic current, harmonic voltage, pulse count value, periodic electric energy, CO 2 conversion value
Main unit tolerancesCurrent, voltage, power, reactive power, apparent power, frequency: ±0.5% (relative to rated input) Electric energy: Class 0.5S (IEC62053-22) Reactive electric energy: Class 2S (IEC62053-23) Harmonic current, harmonic voltage: ±2.5%
Data update cycle250 ms *Electric energy and reactive electric energy are always sampled (following short-cycle load fluctuation also).
External input specification: Input signal formatNon-voltage a-contact or open collector 1 input
External output specification: Output signal formatNon-voltage a-contact, 1 output
External output specification: Pulse output specification: Output itemElectric energy
External output specification: Pulse output specification: Output signal typeNon-voltage a-contact, 1 output ・Pulse units (kWh/pulse): 0.001, 0.01, 0.1, 1, 10, 100
Compatible standardCE marking (EMC: EN-61326-1: 2006, Safety: EN-61010-1: 2010), UL: UL61010-1
Weight0.3kg
External dimensions (unit: mm)75 (W) x 90 (H) x 75 (D) (excluding protruding parts)
