EMU4-D65 Mitsubishi Energy measuring EcoMonitorPlus

MPN: EMU4-D65 · Brand: Mitsubishi Electric (Factory Automation)

Price on request

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)

30-day returns, no restocking fee on unused parts

Ships via

Quick facts

Availability	Confirmed on request
Category	Mitsubishi Energy measuring – Energy Measuring Unit
Lifecycle	Active
Warranty	12-month (new) · 3-month (used/refurbished)

Shipping & availability

When can EMU4-D65 be shipped?

EMU4-D65 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up EMU4-D65 in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for EMU4-D65 and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for EMU4-D65, subject to availability and destination.

The Mitsubishi Electric EMU4-D65 is a ecoMonitorPlus in the Energy measuring. Specifications and manuals below are Mitsubishi Electric's own data.

Specifications

Product

Series	Energy measuring
Category	EcoMonitorPlus
Type	Display unit

Specifications

Category	Energy Saving Supporting Devices
Group	Energy Measuring Unit
Model	EcoMonitorPlus
Use	Display unit
Model name	EMU4-D65
Auxiliary power supply	9V DC *1
Display device	LCD (with backlight)
Display refresh interval	500ms
Measurement value display: Wh+A+4 element	Display of four elements: Electric energy, current and four other elements (selectable) (The number of display digits of electric energy is six digits.)
Measurement value display: Harmonic detail	Display of detailed harmonic order data of harmonic current and harmonic voltage *2
Measurement value display: Other	Display determined elements for each unit
Alarm display: Alarm status display	Display of upper-/lower-limit alarm generating status and contact output status
Alarm display: Alarm value display	Display of upper-/lower-limit alarm values and generating time
Setting: EMU setting	Setting of EcoMonitorPlus/EcoMonitorPro (phase wire, primary voltage, primary current, sensor type, demand time limit, pulse unit, measuring mode, etc.)
Setting: Clock setting	Setting of internal clock of EMU4-LM
Setting: Alarm setting	Setting of upper-limit alarm value and lower-limit alarm value
Setting: Display setting	Setting of LCD (with backlight) contrast and backlight ON status
Data reset	Reset integrated values such as maximum value, minimum value, electric energy(consumption / regeneration), reactive electric energy , pulse count value, pulse conversion value
Data preset	Preset the integrated value such as electric energy (consumption · regeneration), reactive electric energy, pulse count value, pulse conversion value etc
Connection to energy measuring unit	Dedicated cable (supplied with product) used for connection. Cable extension: 10 m max. *3
Max. number of connectable units	7 units (For one basic unit) *3
Installation method	Installs to IEC rail or panel
Operating temperature range	-5℃ to +55℃ (ave. daily temp. of +35℃ or lower)
Operating humidity range	30% to 85%RH (no condensation)
Storage temperature range	-10℃ to +60℃ (ave. daily temp. of +35℃ or lower)
Weight	0.1kg

Downloads & documentation

Official documents from Mitsubishi Electric (Factory Automation), downloaded directly from the manufacturer.

Data sheets & manuals

Energy Measuring Unit (EcoMonitorPlus), Small Type Display Unit for Energy Measuring Unit, Through type zero-phase current transformer, Split type zero-phase current transformer Before using the instr	PDF · 0.39MB
DISPLAY UNIT for (Energy Measuring Unit) Instruction manual (Simplified edition) (MODEL:EMU4-D65) (IB63A22E-F)	PDF · 3.13MB
Small Type Display Unit for Energy Measuring Unit User's Manual (Details) (MODEL:EMU4-D65) (IB63A24-F)	PDF · 3.91MB
