EMU4-PX4 Mitsubishi Energy measuring EcoMonitorPlus

MPN: EMU4-PX4 · Brand: Mitsubishi Electric (Factory Automation)

Price on request

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)

30-day returns, no restocking fee on unused parts

Ships via

Quick facts

Availability	Confirmed on request
Category	Mitsubishi Energy measuring – Energy Measuring Unit
Lifecycle	Active
Warranty	12-month (new) · 3-month (used/refurbished)

Shipping & availability

When can EMU4-PX4 be shipped?

EMU4-PX4 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up EMU4-PX4 in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for EMU4-PX4 and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for EMU4-PX4, subject to availability and destination.

The Mitsubishi Electric EMU4-PX4 is a ecoMonitorPlus in the Energy measuring. Specifications and manuals below are Mitsubishi Electric's own data.

Specifications

Product

Series	Energy measuring
Category	EcoMonitorPlus
Type	Pulse Input Unit

Specifications

Category	Energy Saving Supporting Devices
Group	Energy Measuring Unit
Model	EcoMonitorPlus
Use	Pulse Input Unit
Model name	EMU4-PX4
Input specifications: Number of input contacts	4 points
Input specifications: Input signal format	Non-voltage a-contact or open-collector
Input specifications: Rated input voltage/current	DC6.5V, 10mA
Input specifications: Input pulse conditions	Pulse-on time: 30 ms or more Pulse-off time: 30 ms or more Chattering time: 3 ms or less
Input specifications: Measured items	Pulse input: Pulse count value, pulse conversion value Contact input: Operation time, contact conditions * External input (pulse input/contact input) can be switched. (Switch each channel in the settings.)
Input specifications: Range of measurement values	Pulse count value: 0 to 999,999 Pulse conversion value: 0.001 to 999,999,000
External output: Output signal type	Non-voltage a-contact, 1 output
External output: Functions: Alarm elements	Pulse conversion value upper limit monitoring
Compatible standard	CE marking (EMC: EN-61326-1: 2013, Safety: EN-61010-1: 2010), UL: UL61010-1
Consumption VA: Single unit	110V AC: 2.0VA, 220V AC: 2.5VA
Weight	0.2kg
External dimensions (unit: mm)	37.5 (W) x 90 (H) x 92.9 (D) (excluding protruding parts) (Maximum size including projections: 41.5 (W) x 99 (H) x 92.9 (D))

Downloads & documentation

Official documents from Mitsubishi Electric (Factory Automation), downloaded directly from the manufacturer.

Data sheets & manuals

Energy Measuring Unit (EcoMonitorPlus), Small Type Display Unit for Energy Measuring Unit, Through type zero-phase current transformer, Split type zero-phase current transformer Before using the instr	PDF · 0.39MB
Energy Measuring Unit (EcoMonitorPlus) Extension for Pulse Input / Extension for Analog Input User's Manual (Digest) (MODEL:EMU4-PX4/EMU4-AX4) (IB63C96E-F)	PDF · 1.99MB
Energy Measuring Unit (EcoMonitorPlus) Extension Model for Pulse Input / Extension Model for Analog Input User's Manual (Details) (MODEL:EMU4-PX4/EMU4-AX4) (IB63D01-G)	PDF · 1.89MB
Energy Measuring Unit Programming Manual (CC-Link) For ver.1 remote device station (EcoMonitorPro/EMU3/EcoMonitorLight/EcoMonitorPlus Series) (LEN160305-C)	PDF · 5.53MB
Energy Measuring Unit Programming Manual (CC-Link) For ver.2 remote device station (MODEL:EMU4-BD1-MB/EMU4-HD1-MB/EMU4-BM1-MB/EMU4-HM1-MB/EMU4-LG1-MB/EMU4-A2/EMU4-VA2/EMU4-AX4/EMU4-PX4) (LEN160316-C)	PDF · 6.49MB
Energy Measuring Unit Programming Manual (CC-Link IE Field Network Basic) (SLMP) (MODEL:EMU4-BD1-MB/EMU4-HD1-MB/EMU4-FD1-MB/EMU4-BM1-MB/EMU4-HM1-MB/EMU4-LG1-MB/EMU4-A2/EMU4-VA2/EMU4-AX4/EMU4-PX4) (LEN	PDF · 3.87MB
Energy Measuring Unit Programming Manual (CC-Link IE TSN) (SLMP) (MODEL:EMU4-BD1A-MB/EMU4-HD1A-MB/EMU4-FD1-MB/EMU4-BM1-MB/EMU4-HM1-MB/EMU4-LG1-MB/EMU4-CNT-MB/EMU4-A2/EMU4-VA2/EMU4-AX4/EMU4-PX4) (LEN21	PDF · 8.92MB
Energy Measuring Unit EcoMonitorLight/EcoMonitorPlus Series MODBUS I/F Specification (MODEL:EMU4-BD1-MB/EMU4-HD1-MB/EMU4-BM1-MB/EMU4-HM1-MB/EMU4-LG1-MB/EMU4-CNT-MB/EMU4-A2/EMU4-VA2/EMU4-PX4/EMU4-AX4)	PDF · 3.62MB
