Mitsubishi Electric EMU4-CNT-MB
Mitsubishi Energy measuring EcoMonitorPlus
- MPN
- EMU4-CNT-MB
Discontinued by Mitsubishi Electric (Factory Automation) — we can still source the original EMU4-CNT-MB (new, used or refurbished, subject to availability). Request a quote below.
Request a Quote
- 1We check stock, condition and lead time
- 2You get a written quote by email
- 3Approve it and we ship — in-stock parts within 1 business day
- 12-month warranty (new) · 3-month (used/refurbished)
- 30-day returns, no restocking fee on unused parts
- 100% positive eBay feedback
- Ships via
Have spare Mitsubishi Electric (Factory Automation) parts? We buy surplus →
What is the Mitsubishi Electric EMU4-CNT-MB?
The Mitsubishi Electric EMU4-CNT-MB is a ecoMonitorPlus in the Energy measuring. MODBUS RTU (RS-485) communication. Mitsubishi Electric has discontinued it (2026/03 Discontinued); PartnerPLC sources discontinued Mitsubishi parts on the surplus market for maintenance of existing machines. Specifications and manuals below are Mitsubishi Electric's own data.
Specifications
Product
| Series | Energy measuring |
| Category | EcoMonitorPlus |
| Type | Control Unit |
| Sales status | 2026/03 Discontinued (Mitsubishi Electric) |
| Outline | MODBUS RTU (RS-485) communication |
Specifications
| Category | Energy Saving Supporting Devices |
| Group | Energy Measuring Unit |
| Model | EcoMonitorPlus |
| Use | Control Unit |
| Model name | EMU4-CNT-MB |
| Transmission | MODBUS RTU (RS-485) communication |
| Auxiliary power rating | 100V-240V AC (+10%, -15%) 50Hz/60Hz |
| Consumption VA: Single unit | 9.0VA (at 110V AC: 7.0VA, at 220V AC: 9.0VA) |
| Consumption VA: Max. configuration | 22VA (at 110V AC: 18VA, at 220V AC: 22VA) |
| External output specification: Contact output: Number of output contacts | 3 points |
| External output specification: Contact output: Output signal format | Non-voltage a-contact |
| External output specification: Contact output: Rated output voltage/curren | 35V DC, 75mA or 24V AC, 75mA (power factor = 1) |
| External output specification: Analog output: Number of output contacts | 1 point |
| External output specification: Analog output: Output voltage/current | Voltage output (0 to 5V DC (external load resistance 5kΩ or more)) or current output (4 to 20mA DC (external load resistance 600Ω or less)) * Output range (voltage output/current output) can be changed by setting. |
| Clock operation | 5 min./month difference |
| Compatible standards | EMC: EN61326-1: 2013, UL: UL61010-1, Safety standard: EN-61010-1: 2010 |
| Weight | 0.27kg |
| External dimensions (unit: mm) | 56 (W) x 90 (H) x 92.9 (D) (excluding protrusions) (Max. dimensions including protrusions: 60 (W) x 99 (H) x 94 (D)) |
No matching specifications
Downloads & documentation
Official documents from Mitsubishi Electric (Factory Automation), downloaded directly from the manufacturer.
Data sheets & manuals
- Energy Measuring Unit (EcoMonitorPlus) Control Unit User's Manual (Digest) (MODEL:EMU4-CNT-MB) (IB63E88E-E)
- Energy Measuring Unit (EcoMonitorPlus) Control Unit / Control Unit Engineering Tool User's Manual (Details) (MODEL:EMU4-CNT-MB/EMU4-KNET) (IB63E89-C)
- Energy Measuring Unit (EcoMonitorPlus) Control Unit / Control Unit Engineering Tool User's Manual (Details) (MODEL:EMU4-CNT-MB/EMU4-KNET) (IB63E90-A)
- Energy Measuring Unit (EcoMonitorPlus) Control Unit Remote Monitoring Tool User's Manual (IB63F73-A)
- Energy Measuring Unit (EcoMonitorPlus) Control Unit Remote Monitoring Tool User's Manual (IB63F74)
- Energy Measuring Unit Programming Manual (CC-Link) For ver.1 remote device station (EcoMonitorPro/EMU3/EcoMonitorLight/EcoMonitorPlus Series) (LEN160305-C)
- Energy Measuring Unit Programming Manual (CC-Link) For ver.2 remote device station (MODEL:EMU4-BD1-MB/EMU4-HD1-MB/EMU4-BM1-MB/EMU4-HM1-MB/EMU4-LG1-MB/EMU4-A2/EMU4-VA2/EMU4-AX4/EMU4-PX4) (LEN160316-C)
- Energy Measuring Unit Programming Manual (CC-Link IE Field Network Basic) (SLMP) (MODEL:EMU4-BD1-MB/EMU4-HD1-MB/EMU4-FD1-MB/EMU4-BM1-MB/EMU4-HM1-MB/EMU4-LG1-MB/EMU4-A2/EMU4-VA2/EMU4-AX4/EMU4-PX4) (LEN
- Energy Measuring Unit Programming Manual (CC-Link IE TSN) (SLMP) (MODEL:EMU4-BD1A-MB/EMU4-HD1A-MB/EMU4-FD1-MB/EMU4-BM1-MB/EMU4-HM1-MB/EMU4-LG1-MB/EMU4-CNT-MB/EMU4-A2/EMU4-VA2/EMU4-AX4/EMU4-PX4) (LEN21
- Energy Measuring Unit EcoMonitorLight/EcoMonitorPlus Series MODBUS I/F Specification (MODEL:EMU4-BD1-MB/EMU4-HD1-MB/EMU4-BM1-MB/EMU4-HM1-MB/EMU4-LG1-MB/EMU4-CNT-MB/EMU4-A2/EMU4-VA2/EMU4-PX4/EMU4-AX4)
EMU4-CNT-MB: frequently asked questions
Can I still buy the EMU4-CNT-MB now that it is discontinued?
Yes. Mitsubishi Electric (Factory Automation) has discontinued the EMU4-CNT-MB, but sourcing discontinued parts is what PartnerPLC specialises in — new old stock, used and refurbished units. Request a quote and we'll confirm availability, condition and lead time.
When can EMU4-CNT-MB be shipped?
EMU4-CNT-MB is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.
Can I pick up EMU4-CNT-MB in person?
Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.
Is express delivery available?
Yes — mention it when you request a quote for EMU4-CNT-MB and we'll include express shipping options in our reply.
My factory is down and I need this urgently — can you help?
For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for EMU4-CNT-MB, subject to availability and destination.
