Mitsubishi Electric EMU4-LM

Mitsubishi Energy measuring EcoMonitorLight EcoMonitorPlus

MPN
EMU4-LM
Price and lead time confirmed within 1 business day
Request a Quote
  1. 1We check stock, condition and lead time
  2. 2You get a written quote by email
  3. 3Approve it and we ship — in-stock parts within 1 business day

A real person replies, typically within 1 business day — see our privacy policy.

  • 12-month warranty (new) · 3-month (used/refurbished)
  • 30-day returns, no restocking fee on unused parts
  • 100% positive eBay feedback
  • Ships via

Have spare Mitsubishi Electric (Factory Automation) parts? We buy surplus →

What is the Mitsubishi Electric EMU4-LM?

The Mitsubishi Electric EMU4-LM is a ecoMonitorLight EcoMonitorPlus in the Energy measuring. Specifications and manuals below are Mitsubishi Electric's own data.

Specifications

Product

SeriesEnergy measuring
CategoryEcoMonitorLight EcoMonitorPlus
TypeLogging Unit

Specifications

CategoryEnergy Saving Supporting Devices
GroupEnergy Measuring Unit
ModelEcoMonitorLight EcoMonitorPlus
UseLogging Unit
Model nameEMU4-LM
Ratings6.4V DC (supplied from energy measuring unit)
Power interruption backupTotal power interruption backup time of the battery (EMU4-BT) is one year (ave. daily temp. of 35℃ or lower). It is recommended to replace the battery every three years.
Power interruption backup: Set valueSaved in non-volatile memory * Data will not be lost even if power outage occurs.
Power interruption backup: Logging data System log dataSaved in volatile memory * Data will be lost if power outage occurs when the battery voltage is low (BAT.LED is lit).
Power interruption backup: Timer operationTimer operation continues by using the battery in the event of power outage. * Timer operation stops if the battery voltage is low (BAT.LED is lit) when power outage occurs. After power is recovered, timer operation starts from 2013/01/01 00:00:00.
Clock accuracy1 min/month
Output data storage media *1SD memory card (SD, SDHC)
Compatible modelEnergy measuring unit (EcoMonitorLight) Model: EMU4-BD1-MB, EMU4-HD1-MB Energy measuring unit (EcoMonitorPlus) Model: EMU4-BM1-MB, EMU4-HM1-MB, EMU4-LG1-MB, EMU4-CNT-MB, EMU4-VA2, EMU4-A2, EMU4-AX4, EMU4-PX4
Compatible standardEMC: EN-61326-1: 2013
Usage environment: Operating temperature-5℃ to +55℃ (ave. daily temp. of +35℃ or lower)
Usage environment: Operating humidity30% to 85%RH (no condensation)
Usage environment: Storage temperature-10℃ to +60℃ (ave. daily temp. of +35℃ or lower)
Usage environment: Altitude2,000m or lower
Weight0.1 kg (Wight of logging unit only)
External dimensions (unit: mm)25 (W) x 90 (H) x 60 (D) (excluding protruding parts)
Parts sold separatelySD memory card (EMU4-SD2GB, EMU4-SD16GB) *1*2
Consumables sold separatelyBattery (EMU4-BT) *2
Logging Specification: Logging mode: Automatic updateAutomatic overwrite/update
Logging Specification: Logging mode: Date/time designationAutomatic start/stop according to start time setting
Logging Specification: Logging data type: Detailed dataMeasurement data is saved according to set "Detailed Data Logging Cycle" (1 sec, 1 min, 5 min, 10 min, 15 min, 30 min). * Output as a detailed data file
Logging Specification: Logging data type: 1-Hour dataMeasurement data is saved in 1-hour cycles. * Output as 1-hour and 1-day data files.
Logging Specification: Number of logging elements: Detailed dataDetailed data logging cycle of 1 sec → Maximum of 4 elements Detailed data logging cycle of other than 1 sec → Maximum of 10 elements
Logging Specification: Number of logging elements: 1-Hour dataMaximum of 10 elements
Logging Specification: System log data3,600 records
Logging Specification: Logging data and system log data output formatCSV format (ASCII code)
