Mitsubishi Electric EMU4-LG1-MB
Mitsubishi Energy measuring EcoMonitorPlus
- MPN
- EMU4-LG1-MB
Request a Quote
- 1We check stock, condition and lead time
- 2You get a written quote by email
- 3Approve it and we ship — in-stock parts within 1 business day
- 12-month warranty (new) · 3-month (used/refurbished)
- 30-day returns, no restocking fee on unused parts
- 100% positive eBay feedback
- Ships via
Have spare Mitsubishi Electric (Factory Automation) parts? We buy surplus →
What is the Mitsubishi Electric EMU4-LG1-MB?
The Mitsubishi Electric EMU4-LG1-MB is a ecoMonitorPlus in the Energy measuring. MODBUS RTU (RS-485) communication. Specifications and manuals below are Mitsubishi Electric's own data.
Specifications
Product
| Series | Energy measuring |
| Category | EcoMonitorPlus |
| Type | Insulation Monitor Model |
| Outline | MODBUS RTU (RS-485) communication |
Specifications
| Category | Energy Saving Supporting Devices |
| Group | Energy Measuring Unit |
| Model | EcoMonitorPlus |
| Use | Insulation Monitor Model |
| Model name | EMU4-LG1-MB |
| Transmission | MODBUS RTU (RS-485) communication |
| Phase wire system | Single-phase 2-wire, single-phase 3-wire, 3-phase 3-wire, 3-phase 4-wire common |
| Instrument ratings: Voltage circuit: Single-phase 2-wire 3-phase 3-wire | 110V, 220V, 440V AC common |
| Instrument ratings: Voltage circuit: Single-phase 3-wire | 110V AC (between wires 1 and 2, and wires 2 and 3), 220V AC (between wires 1 and 3) 220V AC (between wires 1 and 2, and wires 2 and 3), 440V AC (between wires 1 and 3) |
| Instrument ratings: Voltage circuit: 3-phase 4-wire | Minimum: 63.5V/110V AC, Maximum: 277V/480V AC |
| Instrument ratings: Current circuit | 1A (Mitsubishi ZCT is used. Primary current value of ZCT is indicated.) |
| Instrument ratings: Frequency | 50/60Hz (automatic frequency selection) |
| Auxiliary power rating | 100V-240V AC (+10%, -15%) 50Hz/60Hz |
| No. of measurement circuits | 1 circuit |
| Consumption VA: Voltage circuit | For each phase: 0.1VA (110V AC), 0.2VA (220V AC), 0.4VA (440V AC) |
| Consumption VA: Auxiliary power circuit | 110V AC: 2.0VA, 220V AC: 3.0VA |
| Measurement items | Leakage current, demanded leakage current, resistance leakage current, demanded resistance leakage current, resistance leakage current difference conversion value |
| Main unit tolerances | Low sensitivity mode Leakage current Io, resistive leakage current Ior: ±2.5% (relative to 10 to 100% of rating) Leakage current Io, resistive leakage current Ior: ±2.5 mA (relative to 10% of rating or lower) High sensitivity mode Leakage current Io, resistive leakage current Ior: ±2.5 mA |
| Data update cycle | Leakage current: 2 sec, resistive leakage current: 2 sec |
| External output specification: Output signal format | Non-voltage a-contact, 1 output |
| Compatible standard | CE marking (EMC: EN-61326-1: 2013, Safety: EN-61010-1: 2010), UL: UL61010-1 |
| Weight | 0.2kg |
| External dimensions (unit: mm) | 37.5 (W) x 90 (H) x 92.9 (D) (excluding protruding parts) (Maximum size including projections: 41.5 (W) x 99 (H) x 94 (D)) |
No matching specifications
Downloads & documentation
Official documents from Mitsubishi Electric (Factory Automation), downloaded directly from the manufacturer.
Data sheets & manuals
- Energy Measuring Unit (EcoMonitorPlus), Small Type Display Unit for Energy Measuring Unit, Through type zero-phase current transformer, Split type zero-phase current transformer Before using the instr
- Energy Measuring Unit (EcoMonitorPlus) with Insulation Monitoring User's Manual (Digest) (MODEL:EMU4-LG1-MB) (IB63A16E-J)
- Energy Measuring Unit (EcoMonitorPlus) Insulation Monitoring Model User's Manual (Details) (MODEL:EMU4-LG1-MB) (IB63A18-H)
- Energy Measuring Unit Programming Manual (CC-Link) For ver.1 remote device station (EcoMonitorPro/EMU3/EcoMonitorLight/EcoMonitorPlus Series) (LEN160305-C)
- Energy Measuring Unit Programming Manual (CC-Link) For ver.2 remote device station (MODEL:EMU4-BD1-MB/EMU4-HD1-MB/EMU4-BM1-MB/EMU4-HM1-MB/EMU4-LG1-MB/EMU4-A2/EMU4-VA2/EMU4-AX4/EMU4-PX4) (LEN160316-C)
- Energy Measuring Unit Programming Manual (CC-Link IE Field Network Basic) (SLMP) (MODEL:EMU4-BD1-MB/EMU4-HD1-MB/EMU4-FD1-MB/EMU4-BM1-MB/EMU4-HM1-MB/EMU4-LG1-MB/EMU4-A2/EMU4-VA2/EMU4-AX4/EMU4-PX4) (LEN
- Energy Measuring Unit Programming Manual (CC-Link IE TSN) (SLMP) (MODEL:EMU4-BD1A-MB/EMU4-HD1A-MB/EMU4-FD1-MB/EMU4-BM1-MB/EMU4-HM1-MB/EMU4-LG1-MB/EMU4-CNT-MB/EMU4-A2/EMU4-VA2/EMU4-AX4/EMU4-PX4) (LEN21
- Energy Measuring Unit EcoMonitorLight/EcoMonitorPlus Series MODBUS I/F Specification (MODEL:EMU4-BD1-MB/EMU4-HD1-MB/EMU4-BM1-MB/EMU4-HM1-MB/EMU4-LG1-MB/EMU4-CNT-MB/EMU4-A2/EMU4-VA2/EMU4-PX4/EMU4-AX4)
