EMU4-CM-MT Mitsubishi Energy measuring EcoMonitorLight

MPN: EMU4-CM-MT · Brand: Mitsubishi Electric (Factory Automation)

Price on request

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)

30-day returns, no restocking fee on unused parts

Ships via

Quick facts

Availability	Confirmed on request
Category	Mitsubishi Energy measuring – Energy Measuring Unit
Lifecycle	Active
Warranty	12-month (new) · 3-month (used/refurbished)

Shipping & availability

When can EMU4-CM-MT be shipped?

EMU4-CM-MT is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up EMU4-CM-MT in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for EMU4-CM-MT and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for EMU4-CM-MT, subject to availability and destination.

The Mitsubishi Electric EMU4-CM-MT is a ecoMonitorLight in the Energy measuring. MODBUS TCP communication. Specifications and manuals below are Mitsubishi Electric's own data.

Specifications

Product

Series	Energy measuring
Category	EcoMonitorLight
Type	MODBUS TCP communication Unit
Outline	MODBUS TCP communication

Specifications

Category	Energy Saving Supporting Devices
Group	Energy Measuring Unit
Model	EcoMonitorLight
Use	MODBUS TCP communication Unit
Model name	EMU4-CM-MT
Compatible model	Energy measuring unit (EcoMonitorLight) Model: EMU4-FD1-MB
Compatible standard	CE marking (EMC: EN-61326-1:2013)
Usage environment: Operating temperature	-5℃ to +55℃ (ave. daily temp. of +35℃ or lower)
Usage environment: Operating humidity	30% to 85%RH (no condensation)
Usage environment: Storage temperature	-10℃ to +60℃
Usage environment: Altitude	2,000m or lower
Weight	0.1 kg (Wight of MODBUS TCP communication Unit only)
External dimensions (unit: mm)	25 (W) x 90 (H) x 60 (D) (excluding protruding parts)
MODBUS TCP Communication Specifications: Transmission	MODBUS TCP communication
MODBUS TCP Communication Specifications: Interface	1 port (10BASE-T/100BASE-TX)
MODBUS TCP Communication Specifications: Tranamission method	Base band
MODBUS TCP Communication Specifications: Numbe of cascade connection stages *1	Max. 4 stages (10BASE-T), Max. 2 stages (100BASE-TX)
MODBUS TCP Communication Specifications: Maximum node-to-node distance	200 m (656.16 ft.)
MODBUS TCP Communication Specifications: Maximum segment length *2	100 m (328.08 ft.)
MODBUS TCP Communication Specifications: Connector applicable for external wining	RJ45
MODBUS TCP Communication Specifications: Cable: 10BASE-T	Cable compliant with the IEEE802.3 10BASE-T Standard (unshielded twisted pair cable (UTP cable), Category 3 or more)
MODBUS TCP Communication Specifications: Cable: 100BASE-TX	Cable compliant with the IEEE802.3 100BASE-T Standard (Shielded twised pair cable (STP cable), Category 5 or more)
MODBUS TCP Communication Specifications: Protocol	MODBUS TCP (Port number 502)
MODBUS TCP Communication Specifications: Number of simultaneously connection	Max. 4 connection
MODBUS TCP Communication Specifications: Functions supported	Auto negotiation (10BASE-T/100BASE-TX automatically detected) Auto MDIX function (straight/crossover cable automatically detected)

Downloads & documentation

Official documents from Mitsubishi Electric (Factory Automation), downloaded directly from the manufacturer.

Data sheets & manuals

Logging Unit, CC-Link Communication Unit, CC-Link IE field network Basic communication Unit, CC-Link TSN communication Unit, MODBUS TCP Communication Unit for Energy Measuring Unit (EcoMonitorLight, E	PDF · 0.37MB
MODBUS(R)TCP Communication Unit for Energy Measuring Unit (EMU4-FD1-MB) User's Manual (MODEL:EMU4-CM-MT) (IB63D24-C)	PDF · 0.75MB
