EMU4-CM-TSN Mitsubishi Energy measuring EcoMonitorLight EcoMonitorPlus

MPN: EMU4-CM-TSN · Brand: Mitsubishi Electric (Factory Automation)

Price on request

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)

30-day returns, no restocking fee on unused parts

Ships via

Quick facts

Availability	Confirmed on request
Category	Mitsubishi Energy measuring – Energy Measuring Unit
Lifecycle	Active
Warranty	12-month (new) · 3-month (used/refurbished)

Shipping & availability

When can EMU4-CM-TSN be shipped?

EMU4-CM-TSN is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up EMU4-CM-TSN in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for EMU4-CM-TSN and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for EMU4-CM-TSN, subject to availability and destination.

The Mitsubishi Electric EMU4-CM-TSN is a ecoMonitorLight EcoMonitorPlus in the Energy measuring. CC-Link IE TSN communication. Specifications and manuals below are Mitsubishi Electric's own data.

Specifications

Product

Series	Energy measuring
Category	EcoMonitorLight EcoMonitorPlus
Type	CC-Link IE TSN communication Unit
Outline	CC-Link IE TSN communication

Specifications

Category	Energy Saving Supporting Devices
Group	Energy Measuring Unit
Model	EcoMonitorLight EcoMonitorPlus
Use	CC-Link IE TSN communication Unit
Model name	EMU4-CM-TSN
Ratings	6.4V DC (Powered by the Energy Measuring Unit)
Compatible model	Energy measuring unit (EcoMonitorLight) Model: EMU4-BD1A-MB, EMU4-HD1A-MB, EMU4-FD1-MB Energy measuring unit (EcoMonitorPlus) Model: EMU4-BM1-MB, EMU4-HM1-MB, EMU4-LG1-MB, EMU4-CNT-MB, EMU4-VA2, EMU4-A2, EMU4-AX4, EMU4-PX4
Compatible standard	CE marking (EMC: EN-61326-1, LVD: EN61010-1)
Usage environment: Operating temperature	-5℃ to +55℃ (ave. daily temp. of +35℃ or lower)
Usage environment: Operating humidity	30% to 85%RH (no condensation)
Usage environment: Storage temperature	-10℃ to +60℃ (ave. daily temp. of +35℃ or lower)
Usage environment: Altitude	2,000m or lower
Weight	0.1 kg (CC-Link IE TSN communication Unit only)
External dimensions (unit: mm)	25 (W) x 90 (H) x 60 (D) (excluding protruding parts)
CC-Link IE TSN communication Specifications: Transmission	CC-Link IE TSN communication
CC-Link IE TSN communication Specifications: Station type	Remote station
CC-Link IE TSN communication Specifications: Interface	1 port (100BASE-TX)
CC-Link IE TSN communication Specifications: Max. connection devices	121 devices
CC-Link IE TSN communication Specifications: CC-Link IE TSN Protocol version	CC-Link IE TSN protocol version 2.0
CC-Link IE TSN communication Specifications: Max. response time when using time-managed polling	150ms
CC-Link IE TSN communication Specifications: CC-Link IE TSN Class	Class A
CC-Link IE TSN communication Specifications: Transmission speed	100Mbps
CC-Link IE TSN communication Specifications: Max. distance between stations	100m
CC-Link IE TSN communication Specifications: Applicable connector for external wining	RJ45
CC-Link IE TSN communication Specifications: Cable	Cable compliant with the IEEE802.3 100BASE-TX standard (Ethernet cable, Category 5e)
CC-Link IE TSN communication Specifications: Protocol	CC-Link IE TSN, SLMP
CC-Link IE TSN communication Specifications: Functions supported	Auto MDIX function (straight/ crossover cable automatically detected)

Downloads & documentation

Official documents from Mitsubishi Electric (Factory Automation), downloaded directly from the manufacturer.

Data sheets & manuals

Logging Unit, CC-Link Communication Unit, CC-Link IE field network Basic communication Unit, CC-Link TSN communication Unit, MODBUS TCP Communication Unit for Energy Measuring Unit (EcoMonitorLight, E	PDF · 0.37MB
CC-Link IE Field Network Basic Communication Unit / CC-Link IE TSN communication Unit (EcoMonitorLight, EcoMonitorPlus) User's Manual (MODEL:EMU4-CM-CIFB/EMU4-CM-TSN) (IB63E27E-F)	PDF · 0.76MB
