What is the Mitsubishi Electric EMU4-CM-C?

The Mitsubishi Electric EMU4-CM-C is a ecoMonitorLight EcoMonitorPlus in the Energy measuring. CC-Link communication. Specifications and manuals below are Mitsubishi Electric's own data.

Specifications

Product

SeriesEnergy measuring
CategoryEcoMonitorLight EcoMonitorPlus
TypeCC-Link communication Unit
OutlineCC-Link communication

Specifications

CategoryEnergy Saving Supporting Devices
GroupEnergy Measuring Unit
ModelEcoMonitorLight EcoMonitorPlus
UseCC-Link communication Unit
Model nameEMU4-CM-C
Ratings6.4V DC (supplied from energy measuring unit)
Compatible modelEnergy measuring unit (EcoMonitorLight) Model: EMU4-BD1-MB, EMU4-HD1-MB Energy measuring unit (EcoMonitorPlus) Model: EMU4-BM1-MB, EMU4-HM1-MB, EMU4-LG1-MB, EMU4-CNT-MB, EMU4-VA2, EMU4-A2, EMU4-AX4, EMU4-PX4
Compatible standardCE marking (EMC: EN-61326-1:2006 (EcoMonitorLight), EMC: EN-61326-1: 2013 (EcoMonitorPlus))
Usage environment: Operating temperature-5℃ to +55℃ (ave. daily temp. of +35℃ or lower)
Usage environment: Operating humidity30% to 85%RH (no condensation)
Usage environment: Storage temperature-10℃ to +60℃ (ave. daily temp. of +35℃ or lower)
Usage environment: Altitude2,000m or lower
Weight0.1 kg (Wight of CC-Link communication unit only)
External dimensions (unit: mm)25 (W) x 90 (H) x 60 (D) (excluding protruding parts)
CC-Link Communication Specification: TransmissionCC-Link communication
CC-Link Communication Specification: Number of Occupied Station1 Station Remote device station (I/o) data and word data can be transmitted
CC-Link Communication Specification: VersionVer.1.10, Ver 2.00 (Set by version charge switch)
CC-Link Communication Specification: Remote Station Number (Station Number)1 to 64
CC-Link Communication Specification: Baud Rate156k, 625k, 2.5M, and 10Mbps (changes according to setting) (The interstation cable length and maximum total extension distance vary according to the transmission speed.)
CC-Link Communication Specification: Max.connected deviceA maximum of 42 units can be connected if configured using only this module.
CC-Link Communication Specification: Cable terminating resistanceUse a specified cable for CC-Link communication connection. Resistance values for terminating resistance are different according to the type of specialized cable used.
