Mitsubishi Electric EMU4-BM1-MB
Mitsubishi Energy measuring EcoMonitorPlus
- MPN
- EMU4-BM1-MB
Request a Quote
- 1We check stock, condition and lead time
- 2You get a written quote by email
- 3Approve it and we ship — in-stock parts within 1 business day
- 12-month warranty (new) · 3-month (used/refurbished)
- 30-day returns, no restocking fee on unused parts
- 100% positive eBay feedback
- Ships via
Have spare Mitsubishi Electric (Factory Automation) parts? We buy surplus →
What is the Mitsubishi Electric EMU4-BM1-MB?
The Mitsubishi Electric EMU4-BM1-MB is a ecoMonitorPlus in the Energy measuring. MODBUS RTU (RS-485) communication. Specifications and manuals below are Mitsubishi Electric's own data.
Specifications
Product
| Series | Energy measuring |
| Category | EcoMonitorPlus |
| Type | Energy Measuring Standard Model |
| Outline | MODBUS RTU (RS-485) communication |
Specifications
| Category | Energy Saving Supporting Devices |
| Group | Energy Measuring Unit |
| Model | EcoMonitorPlus |
| Use | Energy Measuring Standard Model |
| Model name | EMU4-BM1-MB |
| Transmission | MODBUS RTU (RS-485) communication |
| Phase wire system | Single-phase 2-wire, single-phase 3-wire, 3-phase 3-wire common |
| Instrument ratings: Voltage circuit: Single-phase 2-wire 3-phase 3-wire | 110V, 220V AC common |
| Instrument ratings: Voltage circuit: Single-phase 3-wire | 110V AC (between wires 1 and 2, and wires 2 and 3), 220V AC (between wires 1 and 3) |
| Instrument ratings: Current circuit | 50A, 100A, 250A, 400A, 600A (Dedicated split-type current sensor is used. All values indicate primary current values of current sensor.) 5A(Dedicated 5A current sensor is used. Current transformer (CT) is used in two-step configuration together with the 5A current sensor in order to allow a maximum primary current value setting of 30,000A) |
| Instrument ratings: Frequency | 50/60Hz (automatic frequency selection) |
| Auxiliary power rating | 100V-240V AC (+10%, -15%) 50Hz/60Hz |
| No. of measurement circuits | 1 circuit (single-phase 2-wire system: 2 circuits*) *Available for single-phase 2-wire system branched from single-phase 3-wire system. |
| Consumption VA: Voltage circuit | For each phase: 0.1VA (110V AC), 0.2VA (220V AC) |
| Consumption VA: Auxiliary power circuit | 110V AC: 2.0VA, 220V AC: 3.0VA |
| Measurement items | Current, demanded current, voltage, power, demanded power, reactive power, power factor, frequency, electric energy (regenerative, consumption), reactive electric energy, current imbalance rate, voltage imbalance rate, operating time |
| Main unit tolerances | Current, voltage, power, reactive power, apparent power, frequency: ±1.0% (relative to rated input) Power factor: ±3.0% Electric energy: ±2.0% (in 5 to 100% range of rated values; power factor = 1) Reactive electric energy: ±2.5% (in 10 to 100% range of rated values; power factor = 0) |
| Data update cycle | 100msec |
| Compatible standard | CE marking (EMC: EN-61326-1: 2013, Safety: EN-61010-1: 2010), UL: UL61010-1 |
| Weight | 0.2kg |
| External dimensions (unit: mm) | 37.5 (W) x 90 (H) x 92.9 (D) (excluding protruding parts) (Maximum size including projections: 41.5 (W) x 99 (H) x 94 (D)) |
No matching specifications
Downloads & documentation
Official documents from Mitsubishi Electric (Factory Automation), downloaded directly from the manufacturer.
Data sheets & manuals
- Energy Measuring Unit (EcoMonitorPlus), Small Type Display Unit for Energy Measuring Unit, Through type zero-phase current transformer, Split type zero-phase current transformer Before using the instr
- Energy Measuring Unit (EcoMonitorPlus) User's Manual (Digest) (MODEL:EMU4-BM1-MB/EMU4-HM1-MB) (IB63A13E-H)
- Energy Measuring Unit (EcoMonitorPlus) Energy Measuring Standard Model / Energy Measuring High Performance Model User's Manual (Details) (MODEL:EMU4-BM1-MB/EMU4-HM1-MB) (IB63A15-J)
- Energy Measuring Unit Programming Manual (CC-Link) For ver.1 remote device station (EcoMonitorPro/EMU3/EcoMonitorLight/EcoMonitorPlus Series) (LEN160305-C)
- Energy Measuring Unit Programming Manual (CC-Link) For ver.2 remote device station (MODEL:EMU4-BD1-MB/EMU4-HD1-MB/EMU4-BM1-MB/EMU4-HM1-MB/EMU4-LG1-MB/EMU4-A2/EMU4-VA2/EMU4-AX4/EMU4-PX4) (LEN160316-C)
- Energy Measuring Unit Programming Manual (CC-Link IE Field Network Basic) (SLMP) (MODEL:EMU4-BD1-MB/EMU4-HD1-MB/EMU4-FD1-MB/EMU4-BM1-MB/EMU4-HM1-MB/EMU4-LG1-MB/EMU4-A2/EMU4-VA2/EMU4-AX4/EMU4-PX4) (LEN
- Energy Measuring Unit Programming Manual (CC-Link IE TSN) (SLMP) (MODEL:EMU4-BD1A-MB/EMU4-HD1A-MB/EMU4-FD1-MB/EMU4-BM1-MB/EMU4-HM1-MB/EMU4-LG1-MB/EMU4-CNT-MB/EMU4-A2/EMU4-VA2/EMU4-AX4/EMU4-PX4) (LEN21
- Energy Measuring Unit EcoMonitorLight/EcoMonitorPlus Series MODBUS I/F Specification (MODEL:EMU4-BD1-MB/EMU4-HD1-MB/EMU4-BM1-MB/EMU4-HM1-MB/EMU4-LG1-MB/EMU4-CNT-MB/EMU4-A2/EMU4-VA2/EMU4-PX4/EMU4-AX4)
EMU4-BM1-MB: frequently asked questions
When can EMU4-BM1-MB be shipped?
EMU4-BM1-MB is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.
Can I pick up EMU4-BM1-MB in person?
Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.
Is express delivery available?
Yes — mention it when you request a quote for EMU4-BM1-MB and we'll include express shipping options in our reply.
My factory is down and I need this urgently — can you help?
For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for EMU4-BM1-MB, subject to availability and destination.
