What is the Mitsubishi Electric EMU4-BD1A-MB?
The Mitsubishi Electric EMU4-BD1A-MB is a ecoMonitorLight in the Energy measuring. MODBUS RTU (RS-485) communication. Specifications and manuals below are Mitsubishi Electric's own data.
Specifications
Product
| Series | Energy measuring |
| Category | EcoMonitorLight |
| Type | Standard Model |
| Outline | MODBUS RTU (RS-485) communication |
Specifications
| Category | Energy Saving Supporting Devices |
| Group | Energy Measuring Unit |
| Model | EcoMonitorLight |
| Use | Standard Model |
| Model name | EMU4-BD1A-MB |
| Transmission | MODBUS RTU (RS-485) communication |
| Phase wire system | Single-phase 2-wire, single-phase 3-wire, 3-phase 3-wire |
| Instrument ratings: Voltage circuit: Single-phase 2-wire 3-phase 3-wire | 110V, 220V AC common |
| Instrument ratings: Voltage circuit: Single-phase 3-wire | 110V AC (Between 1 and 2 line, 2 and 3 line), 220V AC (Between 1 and 3 line) |
| Instrument ratings: Current circuit | 5A, 50A, 100A, 250A, 400A, 600A AC * Each value refers to the split type current at the primary side of the current sensor. |
| Instrument ratings: Frequency | 50Hz / 60Hz (Auto-detect) |
| Auxiliary power rating | 100V-240V AC (+10%, -15%) 50Hz/60Hz |
| No. of measurement circuits | 1 circuit |
| Measurement items | current, current demand, voltage, power, power demand, reactive power, power factor, frequency, electric energy (consumption, regenerative), reactive electric energy |
| Data update cycle | 250msec |
| Power interruption backup | stored in nonvolatile memory (setting, accumulated value, operating time) |
| Compatible standard | UL: UL61010-1, CE Marking / UKCA Marking (EMC: EN 61326-1, LVD: EN 61010-1) |
| Weight | 0.25kg |
| External dimensions (unit: mm) | 75 (W) x 90 (H) x 75 (D) (Except for the protruding portions) (Maximum dimension including the protruding portions: 79 (W) x 90 (H) x 75 (D)) |
No matching specifications
Downloads & documentation
Official documents from Mitsubishi Electric (Factory Automation), downloaded directly from the manufacturer.
Data sheets & manuals
- Energy Measuring Unit (EcoMonitorLight) Before using the instrument (MODEL:EMU4-BD1A-MB/EMU4-HD1A-MB) (IB63G63E-B)
- Energy Measuring Unit (EcoMonitorLight) User's Manual (MODEL:EMU4-BD1A-MB/EMU4-HD1A-MB) (IB63G65-C)
- Energy Measuring Unit Programming Manual (CC-Link) For ver.1 remote device station (EcoMonitorPro/EMU3/EcoMonitorLight/EcoMonitorPlus Series) (LEN160305-C)
- Energy Measuring Unit Programming Manual (CC-Link) For ver.2 remote device station (MODEL:EMU4-BD1-MB/EMU4-HD1-MB/EMU4-BM1-MB/EMU4-HM1-MB/EMU4-LG1-MB/EMU4-A2/EMU4-VA2/EMU4-AX4/EMU4-PX4) (LEN160316-C)
- Energy Measuring Unit Programming Manual (CC-Link IE Field Network Basic) (SLMP) (MODEL:EMU4-BD1-MB/EMU4-HD1-MB/EMU4-FD1-MB/EMU4-BM1-MB/EMU4-HM1-MB/EMU4-LG1-MB/EMU4-A2/EMU4-VA2/EMU4-AX4/EMU4-PX4) (LEN
- Energy Measuring Unit Programming Manual (CC-Link IE TSN) (SLMP) (MODEL:EMU4-BD1A-MB/EMU4-HD1A-MB/EMU4-FD1-MB/EMU4-BM1-MB/EMU4-HM1-MB/EMU4-LG1-MB/EMU4-CNT-MB/EMU4-A2/EMU4-VA2/EMU4-AX4/EMU4-PX4) (LEN21
- Energy Measuring Unit EcoMonitorLight/EcoMonitorPlus Series MODBUS I/F Specification (MODEL:EMU4-BD1-MB/EMU4-HD1-MB/EMU4-BM1-MB/EMU4-HM1-MB/EMU4-LG1-MB/EMU4-CNT-MB/EMU4-A2/EMU4-VA2/EMU4-PX4/EMU4-AX4)
