B&R 5PP552.0573-00
5.7" TFT VGA color display
- MPN
- 5PP552.0573-00
- Category
- System units
Price and lead time confirmed within 1 business day
Request a Quote
- 12-month warranty (new) · 3-month (used/refurbished)
- 30-day returns, no restocking fee on unused parts
- Ships via
What is the B&R 5PP552.0573-00?
5.7" TFT VGA color display
Function and system keys
Intel® Atom™ technology
Compact installation depth
Fanless operation
Can be upgraded with interface board
Power Panel 552 5.7" VGA TFT display, 20 function and 20 system keys, connections for 1x RS232, 2x USB 2.0, 1x Ethernet 10/100/1000, can be expanded with an interface board, IP65 protection (front), order 24 VDC connector for power supply separately (screw clamp terminal block: 0TB103.9, cage clamp terminal block: 0TB103.91).
Specifications
General information
| Battery – Type | Renata 950 mAh |
| Battery – Service life | 4 years (note: At 50°C, 8.5 µA for the components being supplied and self-discharge of 40%. If an interface board with SRAM is installed, the service life is 2½ years.) |
| Battery – Removable | Yes, accessible from the outside |
| Battery – Variant | Lithium ion |
| Certifications – CE | Yes |
| Certifications – UKCA | Yes |
| Certifications – UL | cULus E115267; Industrial control equipment |
| LEDs | Power, CF, Link, Run |
| B&R ID code | 0xB605 |
| Cooling | Fanless |
| Power button | Yes |
| Reset button | Yes |
| Buzzer | Yes |
Controller
| Power failure logic – Controller | MTCX (note: Maintenance Controller Extended.) |
| Power failure logic – Buffer time | 10 ms |
| Memory – Type | DDR2 SDRAM |
| Memory – Memory size | Max. 2 GB |
| Graphics – Controller | Intel® Graphics Media Accelerator 500 |
| Bootloader | BIOS |
| Mode/Node switches | 2, 16 positions each (back) |
| Watchdog | MTCX |
Display
| Viewing angles – Horizontal | Direction R = 80° / Direction L = 80° |
| Viewing angles – Vertical | Direction U = 80° / Direction D = 80° |
| Backlight – Type | LED |
| Backlight – Brightness (dimmable) | Typ. 20 to 400 cd/m² |
| Backlight – Half-brightness time | 50,000 h (note: At 25°C ambient temperature. Reducing the brightness by 50% can increase the half-brightness time by approximately 50%.) |
| Touch screen – Type | - (note: Touch screen drivers for approved operating systems are available for download in the Downloads section of the B&R website (www.br-automation.com).) |
| Touch screen – Technology | - (note: Touch screen drivers for approved operating systems are available for download in the Downloads section of the B&R website (www.br-automation.com).) |
| Touch screen – Controller | - (note: Touch screen drivers for approved operating systems are available for download in the Downloads section of the B&R website (www.br-automation.com).) |
| Touch screen – Transmittance | - (note: Touch screen drivers for approved operating systems are available for download in the Downloads section of the B&R website (www.br-automation.com).) |
| Type | TFT color |
| Diagonal | 5.7" (144 mm) |
| Colors | 262,144 |
| Resolution | VGA, 640 x 480 pixels |
| Contrast | 850:1 |
Interfaces
| COM1 – Type | RS232, modem supported, not galvanically isolated (note: The COM1 interface is identified in BIOS as the COM A interface.) |
| COM1 – Variant | 9-pin male DSUB connector (note: The COM1 interface is identified in BIOS as the COM A interface.) |
| COM1 – UART | 16550-compatible, 16-byte FIFO buffer (note: The COM1 interface is identified in BIOS as the COM A interface.) |
| COM1 – Max. baud rate | 115 kbit/s (note: The COM1 interface is identified in BIOS as the COM A interface.) |
| CompactFlash slot 1 – Type | Type I |
| SD memory card slot – Type | SD card |
| USB – Quantity | 2 |
| USB – Type | USB 2.0 |
| USB – Variant | Type A |
| USB – Transfer rate | Low speed (1.5 Mbit/s), full speed (12 Mbit/s) to high speed (480 Mbit/s) |
| USB – Current-carrying capacity | Max. 1 A per connection |
| Ethernet – Quantity | 1 |
| Ethernet – Controller | Intel 82574 |
| Ethernet – Variant | Shielded RJ45 port |
| Ethernet – Transfer rate | 10/100/1000 Mbit/s |
Keys
| LED luminous intensity – Yellow | Typ. 38 mcd |
| Function keys | 20 with LED (yellow) |
| System keys | Numeric keys, cursor block |
| Service life | >1,000,000 actuations at 1 ±0.3 N to 3 ±0.3 N actuating force |
Slots
| Interface board | Yes |
| I/O board | No |
Electrical properties
| Nominal voltage | 24 VDC ±25%, SELV (note: IEC 61010-2-201 requirements must be observed.) |
| Nominal current | 1.1 A (note: The specified value applies to a nominal voltage of 24 VDC.) |
| Inrush current | Typ. 3 A, max. 50 A for <300 µs |
| Power consumption | 26 W (note: The specified value applies to a system unit with a CPU board but without an interface board.) |
| Galvanic isolation | Yes |
Operating conditions
| Degree of protection per EN 60529 | Back: IP20 (only with connected CF card, connected IF board or optional IF cover); Front: IP65, protected against dust and hose-directed water |
Ambient conditions
| Temperature – Operation | 0 to 55°C |
| Temperature – Storage | -20 to 60°C |
| Temperature – Transport | -20 to 60°C |
| Relative humidity – Operation | See temperature/humidity diagram |
| Relative humidity – Storage | See temperature/humidity diagram |
| Relative humidity – Transport | See temperature/humidity diagram |
| Vibration – Operation (continuous) | 2 to 9 Hz: 1.75 mm amplitude / 9 to 200 Hz: 0.5 g |
| Vibration – Operation (occasional) | 2 to 9 Hz: 3.5 mm amplitude / 9 to 200 Hz: 1 g |
| Vibration – Storage | 2 to 8 Hz: 7.5 mm amplitude / 8 to 200 Hz: 2 g / 200 to 500 Hz: 4 g |
| Vibration – Transport | 2 to 8 Hz: 7.5 mm amplitude / 8 to 200 Hz: 2 g / 200 to 500 Hz: 4 g |
| Shock – Operation | 15 g, 11 ms |
| Shock – Storage | 30 g, 6 ms |
| Shock – Transport | 30 g, 6 ms |
| Elevation – Operation | Max. 3000 m (component-dependent) (note: The maximum ambient temperature is typically derated 1°C per 1000 meters starting at 500 m above sea level.) |
Mechanical properties
| Housing – Material | Galvanized plate |
| Front – Material | Polyester (note: Visual deviations in color and surface quality are possible due to process or batch conditions.) |
| Front – Light background color | RAL 9006 (note: Visual deviations in color and surface quality are possible due to process or batch conditions.) |
| Front – Dark border color around display | RAL 7024 (note: Visual deviations in color and surface quality are possible due to process or batch conditions.) |
| Front – Frame | Aluminum, naturally anodized (note: Visual deviations in color and surface quality are possible due to process or batch conditions.) |
| Front – Gasket | Flat gasket around display front (note: Visual deviations in color and surface quality are possible due to process or batch conditions.) |
| Dimensions – Width | 302 mm |
| Dimensions – Height | 187 mm |
| Dimensions – Depth | 55 mm |
| Weight | 1750 g |
Accessories
Required accessories (order separately)
| 0TB103.91 | Accessories — One-row 3-pin terminal block 0TB103.9x is used for the power supply. |
| 0TB103.9 | Accessories — One-row 3-pin terminal block 0TB103.9x is used for the power supply. |
| 5PP5CP.US15-02 | CPU boards — Intel Atom Z530 1.6 GHz; Intel US15W chipset; 1x DDR2 memory slot; Intel GMA 500; Insyde BIOS CPU board Intel Atom Z530 1.6 GHz - Single co… |
| 5PP5CP.US15-01 | CPU boards — Intel Atom Z520 1.33 GHz; Intel US15W chipset; 1x DDR2 memory socket; Intel GMA 500; Insyde BIOS CPU board Intel Atom Z520 1.33 GHz - Singl… |
| 5PP5CP.US15-00 | CPU boards — Intel Atom Z510 1.1 GHz; Intel US15W chipset; 1x DDR2 memory socket; Intel GMA 500; Insyde BIOS CPU board Intel Atom Z510 1.1 GHz - Single… |
| 5MMDDR.2048-01 | Main memory — 2048 MB memory; DDR2 SDRAM according to PC2-5300; 64-bit data width; 667 MHz SO-DIMM DDR2 RAM 2048 MB PC2-5300 |
| 5MMDDR.1024-01 | Main memory — 1024 MB memory; DDR2 SDRAM according to PC2-5300; 64-bit data width; 667 MHz SO-DIMM DDR2 RAM 1024 MB PC2-5300 |
| 5MMDDR.0512-01 | Main memory — 512 MB memory; DDR2 SDRAM according to PC2-5300; 64-bit data width; 667 MHz SO-DIMM DDR2 RAM 512 MB PC2-5300 |
Optional accessories (12)
| 4A0006.00-000 | Batteries — Lithium battery, 3 V / 950 mAh, button cell |
| 0AC201.91 | Batteries — Lithium batteries 4 pcs., 3 V / 950 mAh button cell |
| 5CFCRD.2048-06 | CompactFlash cards — 2 GBSLC flash CompactFlash card |
| 5PP5IF.FXCM-00 | Interface boards — 1x CAN bus master interface; 1x X2X Link master interface; 512 kB SRAM; Compatible with the PP500, APC511 and APC511 The 5PP5IF.FXCM-00 int… |
| 5PP5IF.FX2X-00 | Interface boards — 1x X2X Link master interface; 512 kB SRAM; Compatible with the PP500, APC511 and APC511 The 5PP5IF.FX2X-00 interface board has one X2X Link… |
| 5PP5IF.FPLM-00 | Interface boards — 2x POWERLINK interfaces; 512 kB SRAM; Integrated hub for efficient cabling; Configurable ring redundancy; Poll response chaining; Compatibl… |
| 5PP5IF.FETH-00 | Interface boards — 1 network connection (10/100/1000 Mbit/s); 512 kB SRAM; Compatible with the PP500, APC511 and APC511 The interface board 5PP5IF.FETH-00 has… |
| 5PP5IF.FCAN-00 | Interface boards — 1x CAN bus master interface; 512 kB SRAM; Compatible with the PP500, APC511 and APC511 The 5PP5IF.FCAN-00 interface board has one CAN bus m… |
| 5PP5IF.CHDA-00 | Interface boards — 1x MIC; 1x Line IN; 1x Line OUT; Compatible with the PP500, APC511 and APC511 The 5PP5IF.CHDA-00 interface board has an HDA sound chip with… |
| 5PP5IF.CETH-00 | Interface boards — 1 network connection (10/100/1000 Mbit/s); Compatible with the PP500, APC511 and APC511 The interface board 5PP5IF.CETH-00 has a 10/100/100… |
| 5MMUSB.4096-01 | USB accessories — 4 GB; USB 1.1, USB 2.0; High transfer rate; High data storage; Ambient temperature during operation: 0 to 70°C USB 2.0 flash drive 4096 MB… |
| 5MMUSB.2048-01 | USB accessories — 2 GB; USB 1.1, USB 2.0; High transfer rate; High data retention; Ambient temperature during operation: 0 to 70°C USB 2.0 flash drive 2048 M… |
