B&R 5ACCIF02.FPLS-000
Interface card, 2 MB SRAM, 1x RS232 interface
- MPN
- 5ACCIF02.FPLS-000
- Category
- Interface options
Price and lead time confirmed within 1 business day
Request a Quote
- 12-month warranty (new) · 3-month (used/refurbished)
- 30-day returns, no restocking fee on unused parts
- Ships via
- 100% positive eBay feedback
What is the B&R 5ACCIF02.FPLS-000?
Interface card - 2 MB SRAM - 1x RS232 interface - 1x POWERLINK interface - For APC3x00/PPC3x00
Specifications
General information
| Diagnostics – Data transfer | Yes, using LED "Status/Error" |
| Certifications – CE | Yes |
| Certifications – UKCA | Yes |
| Certifications – UL | cULus E115267; Industrial control equipment |
| B&R ID code | 0xF2E2 |
Controller
| SRAM – Size | 2 MB |
| SRAM – Battery-backed | Yes (backup battery of the system unit) |
| SRAM – Remanent variables in power failure mode | 256 kB (for e.g. Automation Runtime, see Automation Help) |
Interfaces
| COM – Quantity | 1 |
| COM – Type | RS232, modem supported, not galvanically isolated |
| COM – Variant | 10-pin, male |
| COM – UART | 16550-compatible, 16-byte FIFO buffer |
| COM – Max. baud rate | 115 kbit/s |
| POWERLINK – Quantity | 1 |
| POWERLINK – Type | Type 4 (note: For additional information, see Automation Help (Communication - POWERLINK - General information - Hardware - IF / LS).) |
| POWERLINK – Variant | RJ45, shielded |
| POWERLINK – Transfer rate | 100 Mbit/s |
| POWERLINK – Transfer | 100BASE-TX |
| POWERLINK – Line length | Max. 100 m between two stations (segment length) |
Electrical properties
| Power consumption | 1.75 W |
Operating conditions
| Pollution degree per EN 61131-2 | Pollution degree 2 |
Ambient conditions
| Temperature – Operation | 0 to 55°C (note: For detailed information, see the temperature tables in the user's manual.) |
| Temperature – Storage | -20 to 60°C |
| Temperature – Transport | -20 to 60°C |
| Relative humidity – Operation | 5 to 90%, non-condensing |
| Relative humidity – Storage | 5 to 95%, non-condensing |
| Relative humidity – Transport | 5 to 95%, non-condensing |
Mechanical properties
| Weight | Approx. 55 g |
Accessories
Optional accessories (1)
| 0TB1210.3100 | Terminal blocks — Two-row 10-pin terminal block 0TB1210.3100 is used to connect to the button/switch interface of the Automation Panel 9xD and to the interfa… |
Downloads & documentation
Official documents from B&R, downloaded directly from the manufacturer.
Data sheets & manuals
CAD & dimension drawings
