Braided hose and fittings Parts
Compare Braided hose and fittings
Key specifications of the parts listed on this page, taken from the manufacturer's data sheets.
| MPN | A dimension IN | A dimension MM | Hose cut off factor IN | Product length in | Product length mm |
|---|---|---|---|---|---|
| 22211-06-06Z | 1.830 | 46.500 | 0.640 | 2.030 | 51.562 |
| 22211-04-04Z | 1.710 | 43.500 | 0.610 | 1.870 | 47.498 |
| 2219TE-06-05TZ | — | 34.000 | 0.000 | 0.433 | 10.998 |
| 22191-32-32WZ | 7.990 | 203.000 | 5.150 | 9.580 | 243.332 |
| 22191-24-24WZ | 6.980 | 177.400 | 4.300 | 4.300 | 109.220 |
| 22191-20-20WZ | 5.720 | 145.500 | 3.600 | 6.710 | 170.434 |
| 22191-16-16Z | 4.900 | 124.500 | 3.050 | 5.710 | 145.034 |
| 22191-12-12Z | 4.070 | 103.400 | 2.550 | 4.700 | 119.380 |
| 22191-06-06Z | 2.560 | 65.250 | 1.380 | 3.000 | 76.200 |
| 22191-06-04FATZ | 2.460 | 62.500 | 1.180 | 2.716 | 68.986 |
| 22191-04-04Z | 2.280 | 58.000 | 1.180 | 2.650 | 67.310 |
| 22141-16-16Z | 5.350 | 136.000 | 3.500 | 6.570 | 166.878 |
| 22141-12-12Z | 4.660 | 118.500 | 3.140 | 5.650 | 143.510 |
| 22141-08-08Z | 3.680 | 93.600 | 2.440 | 4.450 | 113.030 |
| 22141-06-06Z | 3.060 | 77.790 | 1.880 | 3.690 | 93.726 |
| 22111-32-32WZ | 4.290 | 109.000 | 1.450 | 4.890 | 124.206 |
| 22111-24-24WZ | 4.130 | 105.000 | 1.450 | 4.590 | 116.586 |
| 22111-20-20WZ | 3.280 | 83.500 | 1.160 | 3.650 | 92.710 |
| 22111-16-16Z | 2.950 | 75.000 | 1.100 | 3.370 | 85.598 |
| 22111-12-10Z | 2.340 | 59.500 | 1.000 | 2.696 | 68.478 |
| 22111-10-10Z | 2.280 | 58.000 | 0.940 | 2.600 | 66.040 |
| 22111-08-08Z | 2.140 | 54.500 | 0.905 | 2.380 | 60.452 |
| 22111-08-06TZ | 1.960 | 50.000 | 0.780 | 2.200 | 55.880 |
| 22111-06-06Z | 1.980 | 50.500 | 0.800 | 2.190 | 55.626 |
Common to all listed parts
| Construction Style | Crimp |
| End Type 1 | Female BSPP swivel |
| Product material | Carbon steel |
| Thread sealant | No |
