Danfoss 22141-16-16Z

HOSE NIPPLE ASSY, 2P/16, BF/16, CS, STR

MPN: 22141-16-16Z
Category: Braided hose and fittings

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss 22141-16-16Z?

Danfoss HOSE NIPPLE ASSY, 2P/16, BF/16, CS, STR, manufacturer part number 22141-16-16Z. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

A dimension IN	5.350
A dimension MM	136.000
Angle shape	Straight
Brand	Winner by Danfoss
Compatible hose ID IN	1.000
Compatible hose ID MM	25.400
Compatible hoses	EC110, EC210, FC686, FC687, GH663, GH781, GH793
Construction Style	Crimp
End connection torque	162-184 lb-ft(220-250 Nm)
End size 1	-16
End Type 1	Female BSPP swivel
Finish plating	Zinc plating
Hex size 2 IN	1.610
Hex size 2 MM	40.894
Hose cut off factor IN	3.500
Hose cut off factor MM	89.000
Hose size	-16
Inside diameter IN	0.820
Inside diameter MM	21.000
Product height in	3.180
Product height mm	80.772
Product length in	6.570
Product length mm	166.878
Product material	Carbon steel
Product width in	1.610
Product width mm	40.894
Series	Winner 2-Piece
Thread sealant	No
Thread size 1	G 1
