ClimaSys CV Parts
Schneider Electric
NSYCVF575M230MBClimaSys forced vent. roof, 575m3/h, 230V, with roof outlet grille and filter G2, white (RAL 9003)
Schneider Electric
NSYCVF85M48DPFClimaSys forced vent. IP54, 79m3/h, 48V DC, with outlet grille and filter G2
Schneider Electric
NSYCVF85M24DPFClimaSys forced vent. IP54, 80m3/h, 24V DC, with outlet grille and filter G2
Schneider Electric
NSYCVF85M230PFClimaSys forced vent. IP54, 85m3/h, 230V, with outlet grille and filter G2
Schneider Electric
NSYCVF85M115PFClimaSys forced vent. IP54, 85m3/h, 115V, with outlet grille and filter G2
Schneider Electric
NSYCVF850M400PFClimaSys forced vent. IP54, 850m3/h, 400V, with outlet grille and filter G2
Schneider Electric
NSYCVF850M230PFClimaSys forced vent. IP54, 850m3/h, 230V, with outlet grille and filter G2
Schneider Electric
NSYCVF850M115PFClimaSys forced vent. IP54, 850m3/h, 115V, with outlet grille and filter G2
Schneider Electric
NSYCVF65M230PFClimasys forced vent. 65 m3/hour, 230V, with outlet grille plastic and filter
Schneider Electric
NSYCVF65M115PFClimasys forced vent. 65 m3/hour, 115V, with outlet grille plastic and filter
Schneider Electric
NSYCVF575M230MFClimaSys forced vent. roof, 575m3/h, 230V, with roof outlet grille and filter G2, grey (RAL 7035)
Schneider Electric
NSYCVF570M115MFClimaSys forced vent. roof, 570m3/h, 115V, with roof outlet grille and filter G2
Schneider Electric
NSYCVF560M230PFClimaSys forced vent. IP54, 560m3/h, 230V, with outlet grille and filter G2
Schneider Electric
NSYCVF560M115PFClimaSys forced vent. IP54, 560m3/h, 115V, with outlet grille and filter G2
Schneider Electric
NSYCVF54M230MM2Climasys forced vent. 54 m3/h, 230V, 2 metal grilles and 2 anti-insect filters
Compare ClimaSys CV
Key specifications of the parts listed on this page, taken from the manufacturer's data sheets.
| MPN | [Us] rated supply voltage | Absorbed power | [In] rated current | Depth | Net weight |
|---|---|---|---|---|---|
| NSYCVF85M230DG | 175...253 V | 15 W 50 Hz, 17 W 60 Hz | 0.121 A 50 Hz, 0.097 A 60 Hz | External : 62 mm | 0.860 kg |
| NSYCVF850M400DG | 396...466 V | 126 W 50 Hz, 126 W 60 Hz | 0.226 A 50 Hz, 0.232 A 60 Hz | External : 162 mm | 4.500 kg |
| NSYCVF850M230DG | 207...244 V | 150 W 50 Hz, 195 W 60 Hz | 0.65 A 50 Hz, 0.95 A 60 Hz | External : 162 mm | 4.500 kg |
| NSYCVF560M230DG | 207...244 V | 64 W 50 Hz, 80 W 60 Hz | 0.29 A 50 Hz, 0.35 A 60 Hz | External : 161 mm | 3.480 kg |
| NSYCVF38M230DG | 150...250 V | 4.5 W 50 Hz, 4.8 W 60 Hz | 0.16 A 50 Hz, 0.17 A 60 Hz | External : 49 mm | 0.3 kg |
| NSYCVF300M230DG | 145...253 V | 36 W 50 Hz, 37 W 60 Hz | 0.16 A 50 Hz, 0.17 A 60 Hz | External : 116 mm | 1.640 kg |
| NSYCVF165M230DG | — | 15.5 W 50 Hz, 14.4 W 60 Hz | 0.2 A 50 Hz, 0.18 A 60 Hz | External : 104 mm | 1.4 kg |
| NSYCVAC200 | — | — | — | 35 mm | — |
| NSYCVA114M | — | — | — | — | — |
| NSYCVF575M230MB | — | 85 W | — | External : 340 mm | — |
| NSYCVF85M48DPF | 25...55.2 V | 8 W | 0.173 A | External : 62 mm | 0.48 kg |
| NSYCVF85M24DPF | 10...27.6 V | 7.6 W | 0.3 A | External : 62 mm | 0.48 kg |
| NSYCVF85M230PF | 175...253 V | 15 W 60 Hz, 17 W 50 Hz | 0.121 A 50 Hz, 0.097 A 60 Hz | External : 62 mm | 0.78 kg |
| NSYCVF85M115PF | 75...126 V | 15 W 60 Hz, 16 W 50 Hz | 0.207 A 50 Hz, 0.179 A 60 Hz | External : 62 mm | 0.78 kg |
| NSYCVF850M400PF | 396...466 V | 126 W 50 Hz, 126 W 60 Hz | 0.21 A 50 Hz, 0.26 A 60 Hz | External : 162 mm | 4.1 kg |
| NSYCVF850M230PF | 207...244 V | 150 W 50 Hz, 195 W 60 Hz | 0.65 A 50 Hz, 0.85 A 60 Hz | External : 162 mm | 4.1 kg |
| NSYCVF850M115PF | 103...122 V | 145 W 50 Hz, 182 W 60 Hz | 1.279 A 50 Hz, 1.6 A 60 Hz | External : 162 mm | 4.1 kg |
| NSYCVF65M230PF | — | — | — | External : 55 mm | — |
| NSYCVF65M115PF | — | — | — | External : 55 mm | — |
| NSYCVF575M230MF | — | 85 W | — | External : 340 mm | — |
| NSYCVF570M115MF | — | 85 W | — | External : 340 mm | — |
| NSYCVF560M230PF | 207...244 V | 64 W 50 Hz, 80 W 60 Hz | 0.29 A 50 Hz, 0.35 A 60 Hz | External : 161 mm | 3.2 kg |
| NSYCVF560M115PF | 103...122 V | 65 W 50 Hz, 83 W 60 Hz | 0.6 A 50 Hz, 0.72 A 60 Hz | External : 161 mm | 3.2 kg |
| NSYCVF54M230MM2 | — | — | — | External : 38 mm | — |
