Schneider Electric NSYCVF65M115PF
Climasys forced vent. 65 m3/hour, 115V, with outlet grille plastic and filter
- MPN
- NSYCVF65M115PF
- EAN
- 3606480151385
- Category
- ClimaSys CV
Price and lead time confirmed within 1 business day
Discontinued by Schneider Electric — we can still source the original NSYCVF65M115PF (new, used or refurbished, subject to availability). Request a quote below.
Request a Quote
- 12-month warranty (new) · 3-month (used/refurbished)
- 30-day returns, no restocking fee on unused parts
- Ships via
- 100% positive eBay feedback
What is the Schneider Electric NSYCVF65M115PF?
Climasys Forced ventilator with outlet grille plastic and filter. 115 V 50/60 Hz input voltage. Free flow rate w/o filter/grille is 170 m3/h. Free flow rate w/ std. filter is 65 m3/h at 50 Hz. ABS for outlet grille, Polyurethane foam for filter. Black color. IP20. Cut-out dimensions 108 mm.
Specifications
Specifications
| Range | ClimaSys |
| Product name | ClimaSys CV |
| Product or component type | Fan |
| Type of filter | Standard |
| Flow rate | Free flow rate without filter or grille: 170 m3/h, Free flow rate with standard filter: 65 m3/h at 50 Hz |
| Input voltage | 115 V 50/60 Hz |
| Height | External: 124 mm |
| Width | External: 124 mm |
| Depth | External : 55 mm |
| Cut-out dimensions | Ø 108 mm |
| Material | Outlet grille: ABS (acrylonitrile butadiene-styrene), Filter: polyurethane foam |
| Colour | Outlet grille: black, Filter: black |
| IP degree of protection | IP20 |
| Device composition | 1 axial motor, 2 protective grille: on the front and rear surfaces, 1 filter: front of axial motor, 1 outlet grille: front |
Packaging
| Package 1 | 1 PCE, 14.800 cm × 16.500 cm × 6.200 cm (L × W × H), 763.000 g |
| Package 2 | 10 CAR, 30.000 cm × 40.000 cm × 20.000 cm (L × W × H), 7.856 kg |
| Package 3 | 300 PAM, 120.000 cm × 100.000 cm × 75.000 cm (L × W × H), 255.680 kg |
Downloads & documentation
Official documents from Schneider Electric, downloaded directly from the manufacturer.
Data sheets & manuals
NSYCVF65M115PF: frequently asked questions
Can I still buy the NSYCVF65M115PF now that it is discontinued?
Yes. Schneider Electric has discontinued the NSYCVF65M115PF, but sourcing discontinued parts is what PartnerPLC specialises in — new old stock, used and refurbished units. Request a quote and we'll confirm availability, condition and lead time.
When can NSYCVF65M115PF be shipped?
NSYCVF65M115PF is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.
Can I pick up NSYCVF65M115PF in person?
Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.
Is express delivery available?
Yes — mention it when you request a quote for NSYCVF65M115PF and we'll include express shipping options in our reply.
My factory is down and I need this urgently — can you help?
For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for NSYCVF65M115PF, subject to availability and destination.
