Dampened stop gates Parts
Compare Dampened stop gates
Key specifications of the parts listed on this page, taken from the manufacturer's data sheets.
| MPN | Operating temperature [T] max | Workpiece pallet total weight [mG] [kg] | Delivery information | Maximum permissible mass workpiece pallet mG at nominal speed vN 24 m/min | Weight [kg] |
|---|---|---|---|---|---|
| 3842572958 | +5 ... +60 °C | 60 | Assembled | 24 kg | 0.55 |
| 3842563510 | +5 ... +60 °C | 60 | Assembled | 24 kg | 0.55 |
| 3842998748 | 0 ... +60 °C | 250 | Not assembled | — | 0 |
| 3842563511 | +5 ... +60 °C | 175 | Assembled | 50 kg | 1.6 |
| 3842998747 | +5 ... +60 °C | 100 | Not assembled | — | 0 |
| 3842564181 | +5 … +60 °C | 80 | Fully assembled | — | 0.41 |
| 3842572959 | +5 ... +60 °C | 60 | Assembled | 24 kg | 0.55 |
| 3842547785 | +5 ... +60 °C | 60 | Fully assembled | 24 kg | 0.55 |
| 3842567562 | +5 … +60 °C | 220; 220 | — | — | 0.7 |
| 3842524895 | +5 ... +60 °C | 200 | Fully assembled | 55 kg | 1.94 |
| 3842558795 | +5 ... +60 °C | 175 | Fully assembled | 50 kg | 1.6 |
