Linear sets with linear bushings Parts
Compare Linear sets with linear bushings
Key specifications of the parts listed on this page, taken from the manufacturer's data sheets.
| MPN | Shaft diameter d [mm] | Dynamic load capacity C [N] | Dynamic torsional moment load capacity Mt [Nm] | Outer diameter D [mm] | Weight [kg] |
|---|---|---|---|---|---|
| R109921685 | 16.0 | 1260.0 | 5.5 | 26.0 | 2.4 |
| R109921680 | 16.0 | 1260.0 | 5.5 | 26.0 | 1.33 |
| R109921688 | 16.0 | 1260.0 | 5.5 | 26.0 | 0.1 |
| R109921687 | 16.0 | 1260.0 | 5.5 | 26.0 | 1.25 |
| R109921686 | 16.0 | 1260.0 | 5.5 | 26.0 | 0 |
| R109921279 | 12.0 | 1040.0 | 3.2 | 22.0 | 0 |
| R109921289 | 12.0 | 1040.0 | 3.2 | 22.0 | 0 |
| R109921285 | 12.0 | 1040.0 | 3.2 | 22.0 | 1.1 |
| R109921280 | 12.0 | 1040.0 | 3.2 | 22.0 | 0.6 |
| R109921288 | 12.0 | 1040.0 | 3.2 | 22.0 | 0.1 |
| R109921287 | 12.0 | 1040.0 | 3.2 | 22.0 | 0.1 |
| R109921286 | 12.0 | 1040.0 | 3.2 | 22.0 | 0 |
| R109825079 | 50.0 | 9250.0 | 103.0 | 75.0 | 0 |
| R109825089 | 50.0 | 9250.0 | 103.0 | 75.0 | 0 |
| R109825085 | 50.0 | 9250.0 | 103.0 | 75.0 | 0.1 |
| R109825080 | 50.0 | 9250.0 | 103.0 | 75.0 | 13.69 |
| R109825088 | 50.0 | 9250.0 | 103.0 | 75.0 | 0.1 |
| R109825087 | 50.0 | 9250.0 | 103.0 | 75.0 | 0.1 |
| R109825069 | 50.0 | 9250.0 | 103.0 | 75.0 | 0 |
| R109825086 | 50.0 | 9250.0 | 103.0 | 75.0 | 0 |
| R109824079 | 40.0 | 6320.0 | 53.0 | 62.0 | 0 |
| R109824089 | 40.0 | 6320.0 | 53.0 | 62.0 | 0 |
| R109824085 | 40.0 | 6320.0 | 53.0 | 62.0 | 0.1 |
| R109824080 | 40.0 | 6320.0 | 53.0 | 62.0 | 0.45 |
Common to all listed parts
| Series | Torque |
| Type | Linear set |
| Maximum acceleration rate amax [m/s²] | 150.0 |
| Maximum permissible linear speed vmax [m/s] | 3.0 |
| Permissible ambient temperature (min. ... max.) | -10 °C ... +80 °C |
