Schneider Electric TSXDSY64T2K
Discrete output module Modicon Premium - 64 O solid state
- MPN
- TSXDSY64T2K
- EAN
- 3389110725582
- Category
- Modicon Premium
Price and lead time confirmed within 1 business day
Discontinued by Schneider Electric — we can still source the original TSXDSY64T2K (new, used or refurbished, subject to availability). Request a quote below.
Request a Quote
- 1We check stock, condition and lead time
- 2You get a written quote by email
- 3Approve it and we ship — in-stock parts within 1 business day
- 12-month warranty (new) · 3-month (used/refurbished)
- 30-day returns, no restocking fee on unused parts
- 100% positive eBay feedback
- Ships via
What is the Schneider Electric TSXDSY64T2K?
Schneider Electric TSXDSY64T2K — discrete output module Modicon Premium - 64 O solid state. Discontinued by Schneider Electric; the manufacturer's successor is BMXDDO6402K. PartnerPLC sources discontinued and surplus Schneider Electric automation parts — request a quote for price, condition and lead time.
Specifications
Main
| Range of product | Modicon Premium Automation platform |
| Product or component type | Discrete output module |
| Discrete output number | 64 |
| Discrete output type | Solid state protected |
| Discrete output voltage | 24 V DC positive conforming to EN/IEC 61131-2 19...30 V |
Complementary
| Current per channel | 0.1 A |
| Maximum current per module | 5 A |
| Maximum leakage current | 0.1 mA, at 30 V |
| Maximum tungsten load | 1.2 W |
| [Ures] residual voltage | 1.5 V |
| Response time | 1.2 ms |
| Paralleling of outputs | Yes : 3 maximum |
| Output overvoltage protection | By transil diode |
| Reverse polarity protection | Reverse mounted diode |
| Output overload protection | Automatic trip |
| Short-circuit protection | Automatic trip |
| Minimum load impedance | 220 W at state 1 |
| isalotion resistance | > 10 MOhm 500 V |
| Power dissipation | (2.4 W + 0.1 W x No of outputs) |
| Product compatibility | Dial and Power |
| Marking | CE |
| Electrical connection | 4 connectors HE-10 |
| Current consumption | 155 mA at 5 V DC |
| Module format | Standard |
| Net weight | 0.36 kg |
Environment
| Dielectric strength | 1500 V 50/60 Hz 60 s |
| Standards | UL 508; CSA C22.2 No 213 Class I Division 2 Group A; CSA C22.2 No 213 Class I Division 2 Group C; 93/68/EEC; 89/336/EEC; IEC 61131-2; CSA C22.2 No 142; CSA C22.2 No 213 Class I Division 2 Group B; 92/31/EEC; CSA C22.2 No 213 Class I Division 2 Group D; 73/23/EEC |
| Product certifications | RINA; DNV; BV; ABS; GL; RMRS; LR |
| Ambient air temperature for operation | 0…60 °C |
| Ambient air temperature for storage | -25…70 °C |
| Relative humidity | 10…95 % without condensation for operation; 5…95 % without condensation for storage |
| Operating altitude | 0...2000 m |
| Protective treatment | TC |
| IP degree of protection | IP20 |
| Pollution degree | 2 |
No matching specifications
Downloads & documentation
Official documents from Schneider Electric, downloaded directly from the manufacturer.
Data sheets & manuals
TSXDSY64T2K: frequently asked questions
Can I still buy the TSXDSY64T2K now that it is discontinued?
Yes. Schneider Electric has discontinued the TSXDSY64T2K, but sourcing discontinued parts is what PartnerPLC specialises in — new old stock, used and refurbished units. Request a quote and we'll confirm availability, condition and lead time. If you are planning an upgrade instead, Schneider Electric names the BMXDDO6402K as its successor — we can quote both.
When can TSXDSY64T2K be shipped?
TSXDSY64T2K is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.
Can I pick up TSXDSY64T2K in person?
Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.
Is express delivery available?
Yes — mention it when you request a quote for TSXDSY64T2K and we'll include express shipping options in our reply.
My factory is down and I need this urgently — can you help?
For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for TSXDSY64T2K, subject to availability and destination.
