Schneider Electric TSXDMZ28AR – TSX Micro - 28 I/O 100…120 V relay

Name: Schneider Electric TSXDMZ28AR – TSX Micro - 28 I/O 100…120 V relay
Brand: Schneider Electric
SKU: TSXDMZ28AR

MPN: TSXDMZ28AR · Brand: Schneider Electric

Price on request

Discontinued by Schneider Electric — we can still source the original TSXDMZ28AR (new, used or refurbished, subject to availability). Request a quote below.

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)

30-day returns, no restocking fee on unused parts

Ships via

Quick facts

Availability	Confirmed on request
Category	Modicon TSX Micro
Lifecycle	Discontinued
Warranty	12-month (new) · 3-month (used/refurbished)
Country of origin	FR
UPC / EAN	3389110540444
Datasheet	Manufacturer datasheet ↗

Shipping & availability

Can I still buy the TSXDMZ28AR now that it is discontinued?

Yes. Schneider Electric has discontinued the TSXDMZ28AR, but sourcing discontinued parts is what PartnerPLC specialises in — new old stock, used and refurbished units. Request a quote and we'll confirm availability, condition and lead time.

When can TSXDMZ28AR be shipped?

TSXDMZ28AR is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up TSXDMZ28AR in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for TSXDMZ28AR and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for TSXDMZ28AR, subject to availability and destination.

Schneider Electric TSXDMZ28AR — TSX Micro - 28 I/O 100…120 V relay (Modicon TSX Micro). Discontinued by Schneider Electric. PartnerPLC sources discontinued and surplus Schneider Electric automation parts — request a quote for price, condition and lead time.

Specifications

Main

Range of product	Modicon TSX Micro automation platform
Product or component type	Discrete relay I/O base
Discrete input number	16 screw terminal block
Discrete input voltage	100...120 V AC
Discrete input frequency	47...63 Hz
Discrete input current	11 mA at 50 Hz; 13 mA at 60 Hz

Complementary

Input voltage limits	>= 74 V at state 1; < 20 V at state 0
Current state 0 guaranteed	<= 4 mA
Current state 1 guaranteed	>= 6 mA
Response time	< 10 ms output; 11...18 ms input at state 0 to state 1 at 50 Hz; 9...16 ms input at state 0 to state 1 at 60 Hz; 11...24 ms input at state 1 to state 0 at 50 Hz; 10...22 ms input at state 1 to state 0 at 60 Hz
Input compatibility	2-wire proximity sensor
load type	Capacitive
Current consumption	125 mA
Power dissipation in W	5.6 W
Output voltage limits	19…264 V AC; 10...34 V DC
Contacts type and composition	NO
Power consumption in VA	50 VA 24 V AC-12 resistive; 110 VA 48 V AC-12 resistive; 220 VA 110 V AC-12 resistive; 220 VA 220 V AC-12 resistive; 24 VA 24 V AC-15 inductive; 24 VA 48 V AC-15 inductive; 220 VA 220 V AC-15 inductive; 110 VA 110 V AC-15 inductive
Power consumption in W	40 W 24 V DC-12 resistive; 24 W 24 V DC-13 inductive
Isolation voltage	1500 V for 1 s
Insulation resistance	>= 10 mOhm
Net weight	0.5 kg
