Schneider Electric TSXDMZ28DT – TSX Micro - 28 I/O solid state

Name: Schneider Electric TSXDMZ28DT – TSX Micro - 28 I/O solid state
Brand: Schneider Electric
SKU: TSXDMZ28DT

MPN: TSXDMZ28DT · Brand: Schneider Electric

Price on request

Discontinued by Schneider Electric — we can still source the original TSXDMZ28DT (new, used or refurbished, subject to availability). Request a quote below.

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)

30-day returns, no restocking fee on unused parts

Ships via

Quick facts

Availability	Confirmed on request
Category	Modicon TSX Micro
Lifecycle	Discontinued
Warranty	12-month (new) · 3-month (used/refurbished)
Country of origin	FR
UPC / EAN	3389110540451
Datasheet	Manufacturer datasheet ↗

Shipping & availability

Can I still buy the TSXDMZ28DT now that it is discontinued?

Yes. Schneider Electric has discontinued the TSXDMZ28DT, but sourcing discontinued parts is what PartnerPLC specialises in — new old stock, used and refurbished units. Request a quote and we'll confirm availability, condition and lead time.

When can TSXDMZ28DT be shipped?

TSXDMZ28DT is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up TSXDMZ28DT in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for TSXDMZ28DT and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for TSXDMZ28DT, subject to availability and destination.

Schneider Electric TSXDMZ28DT — TSX Micro - 28 I/O solid state (Modicon TSX Micro). Discontinued by Schneider Electric. PartnerPLC sources discontinued and surplus Schneider Electric automation parts — request a quote for price, condition and lead time.

Specifications

Main

Range of product	Modicon TSX Micro automation platform
Product or component type	Discrete solid state I/O base DC
Discrete input number	16 1 HE-10 connector
Discrete input voltage	24 V DC, discrete input logic: positive
Discrete input current	7 mA
Discrete input type	Resistive
Discrete output number	12 screw terminal block
Discrete output voltage	24 V DC
Discrete output current	0.5 mA
Discrete output logic	Positive

Complementary

Input voltage limits	>= 11 V at state 1; < 5 V at state 0
Current state 0 guaranteed	<= 1.5 mA
Current state 1 guaranteed	>= 2.5 mA
Input impedance	3.4 Ohm
Response time	<= 0.5 ms from state 1 to state 0 output; <= 0.5 ms from state 0 to state 1 output; 0.1...7.5 ms from state 1 to state 0 input; 0.1...7.5 ms from state 0 to state 1 input
Input compatibility	2-wire/3-wire proximity sensor
Current consumption	132 mA
Power dissipation in W	3.5 W by module output; 0.15 W by channel output; 5 W input
Output voltage limits	19...30 V
Output current limits	0.625 A
Maximum leakage current	0.5 mA at state 0
[Ures] residual voltage	0.3 V
Load impedance ohmic	48 Ohm
Switching frequency	< 0.6/LI² Hz
Output overvoltage protection	By zener diode
Output short-circuit protection	By current limiter and electronic circuit breaker
Reverse polarity protection	Reverse diode on power supply
Paralleling of outputs	Yes : 2 maximum
Isolation voltage	1500 V for 1 s
Net weight	0.425 kg
