Schneider Electric TSXDMZ28DTK – TSX Micro - 28 I/O solid state
Discontinued by Schneider Electric — we can still source the original TSXDMZ28DTK (new, used or refurbished, subject to availability). Request a quote below.
Request a Quote
Quick facts
| Availability | Confirmed on request |
| Category | Modicon TSX Micro |
| Lifecycle | Discontinued |
| Warranty | 12-month (new) · 3-month (used/refurbished) |
| Country of origin | FR |
| UPC / EAN | 3389110540468 |
| Datasheet | Manufacturer datasheet ↗ |
Shipping & availability
Can I still buy the TSXDMZ28DTK now that it is discontinued?
Yes. Schneider Electric has discontinued the TSXDMZ28DTK, but sourcing discontinued parts is what PartnerPLC specialises in — new old stock, used and refurbished units. Request a quote and we'll confirm availability, condition and lead time.
When can TSXDMZ28DTK be shipped?
TSXDMZ28DTK is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.
Can I pick up TSXDMZ28DTK in person?
Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.
Is express delivery available?
Yes — mention it when you request a quote for TSXDMZ28DTK and we'll include express shipping options in our reply.
My factory is down and I need this urgently — can you help?
For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for TSXDMZ28DTK, subject to availability and destination.
This product is part of the Modicon TSX Micro range, an offer of Programmable Logic Controllers (PLC). This discrete solid state I/O base has 16 discrete inputs (by HE-10 connector) and 12 discrete outputs (by HE-10 connector) with positive output logic. It is a solid state I/O base with residual voltage of 0.3V and power dissipation of 3.5W by module output, 0.15W by channel output, 5W input, an I/O voltage of 24V DC, a current consumption of 132mA and an isolation voltage of 1500V. It weighs 0.33kg. It is suitable for infrastructures, machine and manufacturing control applications. It meets IEC 1131-2 Type 1 standards. The automation platform designed to enhance system's performance. With Micro's accuracy, flexibility and increased productivity, you have a real partner at the heart of the machine. Discontinued by Schneider Electric. PartnerPLC sources discontinued and surplus Schneider Electric automation parts — request a quote for price, condition and lead time.
Specifications
Main
| Range of product | Modicon TSX Micro automation platform |
| Product or component type | Discrete solid state I/O base DC |
| Discrete input number | 16 1 HE-10 connector |
| Discrete input voltage | 24 V DC, discrete input logic: positive |
| Discrete input current | 7 mA |
| Discrete input type | Resistive |
| Discrete output number | 12 1 HE-10 connector |
| Discrete output voltage | 24 V DC |
| Discrete output current | 0.5 mA |
| Discrete output logic | Positive |
Complementary
| Input voltage limits | >= 11 V at state 1; < 5 V at state 0 |
| Current state 0 guaranteed | <= 1.5 mA |
| Current state 1 guaranteed | >= 2.5 mA |
| Input impedance | 3.4 Ohm |
| Response time | <= 0.5 ms from state 1 to state 0 output; <= 0.5 ms from state 0 to state 1 output; 0.1...7.5 ms from state 1 to state 0 input; 0.1...7.5 ms from state 0 to state 1 input |
| Input compatibility | 2-wire/3-wire proximity sensor |
| Current consumption | 132 mA |
| Power dissipation in W | 3.5 W by module output; 0.15 W by channel output; 5 W input |
| Output voltage limits | 19...30 V |
| Output current limits | 0.625 A |
| Maximum leakage current | 0.5 mA at state 0 |
| [Ures] residual voltage | 0.3 V |
| Load impedance ohmic | 48 Ohm |
| Switching frequency | < 0.6/LI² Hz |
| Output overvoltage protection | By zener diode |
| Output short-circuit protection | By current limiter and electronic circuit breaker |
| Reverse polarity protection | Reverse diode on power supply |
| Paralleling of outputs | Yes : 2 maximum |
| Isolation voltage | 1500 V for 1 s |
| Net weight | 0.33 kg |
Environment
| Standards | IEC 1131-2 Type 1 |
Downloads & documentation
Official documents from Schneider Electric, downloaded directly from the manufacturer.
Data sheets & manuals
| Product data sheet TSXDMZ28DTK |
More Schneider Electric parts
Available on requestTSX Micro - 16 I/O solid state
Available on requestTSX Micro - 28 I/O 100…120 V relay
Available on requestTSX Micro - 28 I/O 24 V DC relay
Available on requestTSX Micro - 28 I/O solid state
Available on requestTSX Micro - 64 I/O solid state
Available on requestETHERNET MANUALAvailable on requestreference manual for Ethernet network (10BASE-5) - French
Available on requestdiscrete output module Modicon Premium - 8 O relay
