Schneider Electric HMIG5U2 – base unit, Harmony GTU, open box, 32GB CFast card

Name: Schneider Electric HMIG5U2 – base unit, Harmony GTU, open box, 32GB CFast card
Brand: Schneider Electric
SKU: HMIG5U2

MPN: HMIG5U2 · Brand: Schneider Electric

Price on request

Discontinued by Schneider Electric — we can still source the original HMIG5U2 (new, used or refurbished, subject to availability). Request a quote below.

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)

30-day returns, no restocking fee on unused parts

Ships via

Quick facts

Availability	Confirmed on request
Category	Harmony GTU HMI
Lifecycle	Discontinued
Warranty	12-month (new) · 3-month (used/refurbished)
Country of origin	CN
UPC / EAN	3606481213785
Datasheet	Manufacturer datasheet ↗

Shipping & availability

Can I still buy the HMIG5U2 now that it is discontinued?

Yes. Schneider Electric has discontinued the HMIG5U2, but sourcing discontinued parts is what PartnerPLC specialises in — new old stock, used and refurbished units. Request a quote and we'll confirm availability, condition and lead time.

When can HMIG5U2 be shipped?

HMIG5U2 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up HMIG5U2 in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for HMIG5U2 and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for HMIG5U2, subject to availability and destination.

This product is part of the Harmony GTU range, an offer of High performance IoT-ready modular HMI panels from 7 to 19inch (Width) screen. The open box features Intel X86 1.33GHz processor and 32GB CFast card data storage, suits for universal panel. It is designed with backup memory of NVRAM 512kB and internal memory of RAM 2GB. This open box supports Windows Embedded 7 operating system. It is equipped with 10BASE-T/100BASE-TX/1000BASE-T Ethernet port. Communication port protocols are Modbus, Modbus TCP/IP and Uni-Telway. Its dimensions are 188mm (width) x 45mm (depth) x 131mm (height) and weighs 0.9kg. This product is certified by ATEX, CE, CULus, IEC, CUL, GL, LR, BV, RCM and EAC. It meets CSA C22.2 No 142, ANSI/ISA 12-12-01, UL 508, Class I division 2 CSA C22.2 No 213 and IEC 61132-2 standards. Harmony GTU (formerly known as Magelis GTU) are universal panels that include smartphone-like interface and Wireless technology. They offer unmatched comfort of use with no compromise on performance and openness. Discontinued by Schneider Electric. PartnerPLC sources discontinued and surplus Schneider Electric automation parts — request a quote for price, condition and lead time.

Specifications

Main

Range of product	Harmony GTU
Product or component type	Base unit
Device short name	Open Box
Range compatibility	Harmony GTU
[Us] rated supply voltage	12...24 V DC power supply

Complementary

Integrated connection type	Ethernet TCP/IP with 2 RJ45; COM1 serial link RJ45 RS485, transmission rate: 110...115200 bit/s; COM2 serial link SUB-D 9 RS232C/RS422/RS485, transmission rate: 110...115200 bit/s; Auxiliary port terminal block; Expansion unit fieldbus card; USB 2.0 port mini B USB; DVI-D video port DVI-D; Microphone mini-jack; USB 2.0 port with 3 USB type A
Communication port protocol	Modbus; Modbus TCP/IP; Uni-Telway
Operating system	Windows Embedded 7
Software package	Internet Explorer; Vijeo Citect web client; Vijeo Designer run time; .NET framework 4.0; Adobe PDF reader; Multimedia player; Office reader; VNC client/server
Processor name	Intel X86 1.33 GHz
Data storage equipment	32 GB CFast card
Port Ethernet	10BASE-T/100BASE-TX/1000BASE-T
Memory description	512 KB NVRAM backup memory; 2 GB RAM internal
Type of cooling	Natural convection
Width	188 mm
Height	131 mm
Depth	45 mm
Net weight	0.9 kg

Environment

Standards	CSA C22.2 No 142; ANSI/ISA 12-12-01; UL 508; Class I division 2 CSA C22.2 No 213; IEC 61132-2
Product certifications	CE; CULus; ATEX; IEC-Ex; RCM; GL; KC; CUL; EAC; ABS; BV; CCS; DNV; LR; RINA; UKCA; UKEX
Ambient air temperature for operation	0…60 °C
Ambient air temperature for storage	-20…60 °C
Pollution degree	2 conforming to IEC 61131-2 ed.3
Relative humidity	10…90 % non-condensing
Operating altitude	2000
Vibration resistance	3.5 mm constant amplitude (f = 5…9 Hz) conforming to IEC 61131-2; 9.8 m/s² (f = 9…150 Hz) conforming to IEC 61131-2
Electromagnetic compatibility	Electrostatic discharge immunity test level 3 conforming to IEC 61000-4-2
