Schneider Electric 170ADI54050

Discrete input module Modicon Momentum - 16 Input 100..120 V AC

MPN
170ADI54050
EAN
3595861147522
Price and lead time confirmed within 1 business day
Request a Quote
  1. 1We check stock, condition and lead time
  2. 2You get a written quote by email
  3. 3Approve it and we ship — in-stock parts within 1 business day

A real person replies, typically within 1 business day — see our privacy policy.

  • 12-month warranty (new) · 3-month (used/refurbished)
  • 30-day returns, no restocking fee on unused parts
  • 100% positive eBay feedback
  • Ships via

Have spare Schneider Electric parts? We buy surplus →

What is the Schneider Electric 170ADI54050?

This input base is part of the Modicon Momentum range, an offer of controller and IP20 monoblock I/Os for distributed control architecture. This discrete input base AC module offers 2 groups of 8 inputs, conforming to IEC 1131-2 type 2 with positive discrete input logic. It is a module with discrete input voltage of 120V AC. There is an isolation between group, channels and bus at 1780V AC. It features 16 LEDs for channel status signaling. Its dimensions are 125mm (width) x 47.5mm (depth) x 141.5mm (height). It weighs 0.284kg. The main application of this module is infrastructures and energy, material handling, simple machine control. This product is certified by CE, FM Class 1 Division 2, CSA and UL. It is suitable for wall mount. Momentum is a flexible, modular family of components that easily snaps together and can be configured for a wide range of distributed I/O and control applications. System with 4 fundamental components that easily snap together in various combinations to form versatile control systems or sub-systems. PartnerPLC sources new and surplus Schneider Electric automation parts — request a quote for price, condition and lead time.

Specifications

Main

Range of productModicon Momentum automation platform
Product or component typeDiscrete inputs base AC
Group of channels2 groups of 8 inputs
Discrete input number16
Discrete input logicPositive

Complementary

Voltage range0...132 V
Isolation between group1780 V AC
Isolation between channels and bus1780 V AC
Terminals description PLC n°1(N)PW; (5)IN_DIS#5; (13)IN_DIS#13; (15)IN_DIS#15; (12)IN_DIS#12; (10)IN_DIS#10; (14)IN_DIS#14; (11)IN_DIS#11; (9)IN_DIS#9; (7)IN_DIS#7; (L1)PW; (1)IN_DIS#1; (8)IN_DIS#8; (2)IN_DIS#2; (6)IN_DIS#6; (16)IN_DIS#16; (3)IN_DIS#3; TB; (4)IN_DIS#4
Local signalling16 LEDs for channel status
Height141.5 mm
Width125 mm
Depth47.5 mm
Net weight0.284 kg

Environment

Protective treatmentTC
MarkingCE

Downloads & documentation

Official documents from Schneider Electric, downloaded directly from the manufacturer.

Data sheets & manuals

170ADI54050: frequently asked questions

When can 170ADI54050 be shipped?

170ADI54050 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up 170ADI54050 in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for 170ADI54050 and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 170ADI54050, subject to availability and destination.
