Schneider Electric 170ADI35000

Discrete input module Modicon Momentum - 32 Input 24 V DC

MPN
170ADI35000
EAN
3595861000254
Price and lead time confirmed within 1 business day
Request a Quote
  1. 1We check stock, condition and lead time
  2. 2You get a written quote by email
  3. 3Approve it and we ship — in-stock parts within 1 business day

A real person replies, typically within 1 business day — see our privacy policy.

  • 12-month warranty (new) · 3-month (used/refurbished)
  • 30-day returns, no restocking fee on unused parts
  • 100% positive eBay feedback
  • Ships via

Have spare Schneider Electric parts? We buy surplus →

What is the Schneider Electric 170ADI35000?

This input base is part of the Modicon Momentum range, an offer of controller and IP20 monoblock I/Os for distributed control architecture. This discrete input base DC module offers 2 groups of 16 inputs, conforming to IEC 1131-2 type 1 with positive discrete input logic. It is a module with discrete input voltage of 24V DC. There is an isolation between channels and ground at 500V AC. It features 32 LEDs for channel status signaling. Its dimensions are 125mm (width) x 47.5mm (depth) x 141.5mm (height). It weighs 0.2kg. The main application of this module is infrastructures and energy, material handling, simple machine control. This product is certified by CE, CSA and UL. It is suitable for wall mount. Momentum is a flexible, modular family of components that easily snaps together and can be configured for a wide range of distributed I/O and control applications. System with 4 fundamental components that easily snap together in various combinations to form versatile control systems or sub-systems.

Specifications

Specifications

Range of productModicon Momentum automation platform
Product or component typeDiscrete inputs base DC
Group of channels2 groups of 16 inputs
Discrete input number32 conforming to IEC 1131-2 Type 1
Discrete input voltage24 V DC
Protective treatmentTC
Discrete input logicPositive
Input voltage limits24 V
Voltage range- 3...30 V
Voltage state 0 guaranteed-3...5 V
Voltage state 1 guaranteed11...30 V
Current state 0 guaranteed<= 1.2 mA
Current state 1 guaranteed>= 2.5 mA
Input resistance4 kOhm
Response time2.2 ms from state 0 to state 1, 3.3 ms from state 1 to state 0
Isolation between channels and bus500 V AC
Power dissipation5.5 W typical, 8.5 W maximum
Terminals description PLC n°1(5)IN_DIS#5, (L+)PW_POS, (12)IN_DIS#12, (9)IN_DIS#9, (14)IN_DIS#14, (7)IN_DIS#7, (4)IN_DIS#4, (6)IN_DIS#6, (10)IN_DIS#10, (2)IN_DIS#2, (8)IN_DIS#8, (M-)PW_NEG, (16)IN_DIS#16, (13)IN_DIS#13, (15)IN_DIS#15, (11)IN_DIS#11, (1)IN_DIS#1, (3)IN_DIS#3, TB
Terminals description PLC n°2TB_1, (13)IN_DIS#29, (4)IN_DIS#20, (1L+)PW_POS, (11)IN_DIS#27, (8)IN_DIS#24, (6)IN_DIS#22, (16)IN_DIS#32, (1)IN_DIS#17, (2)IN_DIS#18, (2L+)PW_POS, (10)IN_DIS#26, (5)IN_DIS#21, (9)IN_DIS#25, (3)IN_DIS#19, (12)IN_DIS#28, (14)IN_DIS#30, (7)IN_DIS#23, (15)IN_DIS#31
MarkingCE
Local signalling32 LEDs for channel status
Current consumption<= 250 mA at 24 V DC
Depth47.5 mm
Height141.5 mm
Width125 mm
Net weight0.2 kg
Product certificationsUL, CSA
Resistance to electrostatic discharge4 kV contact conforming to IEC 801-2, 8 kV on air conforming to IEC 801-2
Resistance to electromagnetic fields10 V/m 80...1000 MHz conforming to IEC 801-3
Ambient air temperature for operation0…60 °C
Ambient air temperature for storage-40…85 °C
Relative humidity95 % without condensation
Operating altitude<= 5000 m

Packaging

Package 11 PCE, 25.900 cm × 18.300 cm × 5.900 cm (L × W × H), 388.000 g
Package 210 S03, 40.000 cm × 30.000 cm × 30.000 cm (L × W × H), 4.466 kg
Package 380 P06, 80.000 cm × 60.000 cm × 75.000 cm (L × W × H), 46.000 kg

Downloads & documentation

Official documents from Schneider Electric, downloaded directly from the manufacturer.

Data sheets & manuals

170ADI35000: frequently asked questions

When can 170ADI35000 be shipped?

170ADI35000 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up 170ADI35000 in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for 170ADI35000 and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 170ADI35000, subject to availability and destination.
