Schneider Electric 140EHC20200C

Modicon Quantum - high-speed counter module - 500000 Hz

MPN
140EHC20200C
EAN
3595861136205
Price and lead time confirmed within 1 business day

Discontinued by Schneider Electric — we can still source the original 140EHC20200C (new, used or refurbished, subject to availability). Request a quote below.

Request a Quote
  1. 1We check stock, condition and lead time
  2. 2You get a written quote by email
  3. 3Approve it and we ship — in-stock parts within 1 business day

A real person replies, typically within 1 business day — see our privacy policy.

  • 12-month warranty (new) · 3-month (used/refurbished)
  • 30-day returns, no restocking fee on unused parts
  • 100% positive eBay feedback
  • Ships via

Have spare Schneider Electric parts? We buy surplus →

What is the Schneider Electric 140EHC20200C?

Schneider Electric 140EHC20200C — Modicon Quantum - high-speed counter module - 500000 Hz. Discontinued by Schneider Electric; the manufacturer's successor is BMXEHC0200H. PartnerPLC sources discontinued and surplus Schneider Electric automation parts — request a quote for price, condition and lead time.

Specifications

Main

Range of productModicon Quantum automation platform
Product or component typeHigh-speed counter module
Number of channels2

Complementary

Addressing requirement6 input words; 6 output words
Data format2147483647 dec 32 bits; 65535 dec 16 bits
Counting input typeIncremental or quadrature
Counting frequency500000 Hz
Discrete input voltage< 30 V
Operating modeIncremental or quadrature discrete input
Input resistance10 kOhm discrete input
Operating threshold0...11 V single ended mode 24 V DC at state off; 0...2 V single ended mode 5 V DC at state on; 0 V single ended mode 12 V DC at state on; 13...24 V single ended mode 24 V DC at state on; 2...7 V single ended mode 12 V DC at state off; >= 1.8 V differential mode; 3.5...5 V single ended mode 5 V DC at state off
Discrete output number4
Discrete output typeField Effect Transistor (FET)
Discrete output voltage0 V switch off DC; 0.4 V switch on DC
Load current0.5 A
Maximum leakage current0.4 mA state off
Maximum voltage drop<0.4 V state on
Protection type36 V transorb for discrete output
Isolation between channels and bus1780 Vrms for 60 s
Fault typeLoss of output field power
Output short-circuit protectionBlown fuse 2.5 A
Power dissipation4 + (0.4 x total module load current)
Bus current requirement650 mA
External power requirement19.2...30 V
Rack typeLocal; Remote; Distributed
Local signalling2 LEDs for channel status
MarkingCE
Current consumption<= 1050 mA at 24 V DC external power supply
Module formatStandard

Environment

Resistance to electrostatic discharge4 kV contact conforming to IEC 801-2; 8 kV on air conforming to IEC 801-2
Resistance to electromagnetic fields10 V/m 80…1000 MHz conforming to IEC 801-3
Ambient air temperature for operation0…60 °C
Ambient air temperature for storage-40…85 °C
Relative humidity95 % without condensation
Operating altitude<= 5000 m
Protective treatmentConformal coating Humiseal 1A33
StandardsUL 508
Product certificationsCSA No 142; C-Tick.1; FM Class 1 Division 2; UL

Downloads & documentation

Official documents from Schneider Electric, downloaded directly from the manufacturer.

Data sheets & manuals

140EHC20200C: frequently asked questions

Can I still buy the 140EHC20200C now that it is discontinued?

Yes. Schneider Electric has discontinued the 140EHC20200C, but sourcing discontinued parts is what PartnerPLC specialises in — new old stock, used and refurbished units. Request a quote and we'll confirm availability, condition and lead time. If you are planning an upgrade instead, Schneider Electric names the BMXEHC0200H as its successor — we can quote both.

When can 140EHC20200C be shipped?

140EHC20200C is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up 140EHC20200C in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for 140EHC20200C and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 140EHC20200C, subject to availability and destination.
