Schneider Electric 140EHC10500C

Modicon Quantum - high-speed counter module - 8 I - 100000 Hz

MPN
140EHC10500C
EAN
3595861136311
Price and lead time confirmed within 1 business day

Discontinued by Schneider Electric — we can still source the original 140EHC10500C (new, used or refurbished, subject to availability). Request a quote below.

Request a Quote
  1. 1We check stock, condition and lead time
  2. 2You get a written quote by email
  3. 3Approve it and we ship — in-stock parts within 1 business day

A real person replies, typically within 1 business day — see our privacy policy.

  • 12-month warranty (new) · 3-month (used/refurbished)
  • 30-day returns, no restocking fee on unused parts
  • 100% positive eBay feedback
  • Ships via

Have spare Schneider Electric parts? We buy surplus →

What is the Schneider Electric 140EHC10500C?

Schneider Electric 140EHC10500C — Modicon Quantum - high-speed counter module - 8 I - 100000 Hz. Discontinued by Schneider Electric; the manufacturer's successor is BMXEHC0800H. PartnerPLC sources discontinued and surplus Schneider Electric automation parts — request a quote for price, condition and lead time.

Specifications

Main

Range of productModicon Quantum automation platform
Product or component typeHigh-speed counter module
Number of channels5

Complementary

Number of inputs8
Addressing requirement12 output words; 12 input words
Data format2147483647 dec 32 bits; 65535 dec 16 bits
Counting input voltage30 V DC max
Counting input current7 mA
Counting input typeDiscrete incremental counter
Counting frequency100000 Hz
Duty cycle1/1 counter input
Discrete input current5 mA
Operating threshold15...30 V single ended mode 24 V REF DC at state on; 3...5 V single ended mode 24 V REF DC at state off
Discrete output number8
Discrete output typeField Effect Transistor (FET)
Discrete output voltage0 V switch off DC; 20...30 V switch on DC
Load current0.21 A
Maximum leakage current0.1 mA state off
Maximum voltage drop<1.25 V state on
Isolation between channels and bus500 Vrms for 60 s
Fault typeLoss of output field power
Output short-circuit protectionInternal
Power dissipation>= 6 W
Bus current requirement250 mA
External power requirement19.2...30 V
Rack typeRemote; Distributed; Local
Local signalling5 LEDs for channel status
MarkingCE
Current consumption<= 1140 mA at 24 V DC external power supply
Module formatStandard

Environment

Resistance to electrostatic discharge4 kV contact conforming to IEC 801-2; 8 kV on air conforming to IEC 801-2
Resistance to electromagnetic fields10 V/m 80…1000 MHz conforming to IEC 801-3
Ambient air temperature for operation0…60 °C
Ambient air temperature for storage-40…85 °C
Relative humidity95 % without condensation
Operating altitude<= 5000 m
Protective treatmentConformal coating Humiseal 1A33
StandardsUL 508
Product certificationsABS; RRS; UL; C-Tick; GL; GOST; DNV; CSA Class 1 Division 2; RINA; LR

Downloads & documentation

Official documents from Schneider Electric, downloaded directly from the manufacturer.

Data sheets & manuals

140EHC10500C: frequently asked questions

Can I still buy the 140EHC10500C now that it is discontinued?

Yes. Schneider Electric has discontinued the 140EHC10500C, but sourcing discontinued parts is what PartnerPLC specialises in — new old stock, used and refurbished units. Request a quote and we'll confirm availability, condition and lead time. If you are planning an upgrade instead, Schneider Electric names the BMXEHC0800H as its successor — we can quote both.

When can 140EHC10500C be shipped?

140EHC10500C is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up 140EHC10500C in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for 140EHC10500C and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 140EHC10500C, subject to availability and destination.
