Schneider Electric 140EHC10500 – Modicon Quantum - high-speed counter module - 8 I - 100000 Hz
Discontinued by Schneider Electric — we can still source the original 140EHC10500 (new, used or refurbished, subject to availability). Request a quote below.
Request a Quote
Quick facts
| Availability | Confirmed on request |
| Category | Modicon Quantum |
| Lifecycle | Discontinued |
| Warranty | 12-month (new) · 3-month (used/refurbished) |
| Country of origin | FR |
| UPC / EAN | 3595861000124 |
| Recommended replacement | BMXEHC0800 |
| Datasheet | Manufacturer datasheet ↗ |
Shipping & availability
Can I still buy the 140EHC10500 now that it is discontinued?
Yes. Schneider Electric has discontinued the 140EHC10500, but sourcing discontinued parts is what PartnerPLC specialises in — new old stock, used and refurbished units. Request a quote and we'll confirm availability, condition and lead time. If you are planning an upgrade instead, Schneider Electric names the BMXEHC0800 as its successor — we can quote both.
When can 140EHC10500 be shipped?
140EHC10500 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.
Can I pick up 140EHC10500 in person?
Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.
Is express delivery available?
Yes — mention it when you request a quote for 140EHC10500 and we'll include express shipping options in our reply.
My factory is down and I need this urgently — can you help?
For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 140EHC10500, subject to availability and destination.
Schneider Electric 140EHC10500 — Modicon Quantum - high-speed counter module - 8 I - 100000 Hz. Discontinued by Schneider Electric; the manufacturer's successor is BMXEHC0800. PartnerPLC sources discontinued and surplus Schneider Electric automation parts — request a quote for price, condition and lead time.
Specifications
Main
| Range of product | Modicon Quantum automation platform |
| Product or component type | High-speed counter module |
| Number of channels | 5 |
Complementary
| Number of inputs | 8 |
| Addressing requirement | 12 output words; 12 input words |
| Data format | 2147483647 dec 32 bits; 65535 dec 16 bits |
| Counting input voltage | 30 V DC max |
| Counting input current | 7 mA |
| Counting input type | Discrete incremental counter |
| Counting frequency | 100000 Hz |
| Duty cycle | 1/1 counter input |
| Discrete input current | 5 mA |
| Operating threshold | 15...30 V single ended mode 24 V REF DC at state on; 3...5 V single ended mode 24 V REF DC at state off |
| Discrete output number | 8 |
| Discrete output type | Field Effect Transistor (FET) |
| Discrete output voltage | 0 V switch off DC; 20...30 V switch on DC |
| Load current | 0.21 A |
| Maximum leakage current | 0.1 mA state off |
| Maximum voltage drop | <1.25 V state on |
| Isolation between channels and bus | 500 Vrms for 60 s |
| Fault type | Loss of output field power |
| Output short-circuit protection | Internal |
| Power dissipation | >= 6 W |
| Bus current requirement | 250 mA |
| External power requirement | 19.2...30 V |
| Rack type | Local; Distributed; Remote |
| Local signalling | 5 LEDs for channel status |
| Marking | CE |
| Current consumption | <= 1140 mA at 24 V DC external power supply |
| Module format | Standard |
Environment
| Resistance to electrostatic discharge | 4 kV contact conforming to IEC 801-2; 8 kV on air conforming to IEC 801-2 |
| Resistance to electromagnetic fields | 10 V/m 80…1000 MHz conforming to IEC 801-3 |
| Ambient air temperature for operation | 0…60 °C |
| Ambient air temperature for storage | -40…85 °C |
| Relative humidity | 95 % without condensation |
| Operating altitude | <= 5000 m |
| Standards | UL 508 |
| Product certifications | RINA; UL; GOST; LR; CSA Class 1 Division 2; RRS; ABS; GL; DNV; C-Tick |
