Schneider Electric 140EHC20200 – Modicon Quantum - high-speed counter module - 500000 Hz

MPN: 140EHC20200 · Brand: Schneider Electric

Price on request

Discontinued by Schneider Electric — we can still source the original 140EHC20200 (new, used or refurbished, subject to availability). Request a quote below.

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)

30-day returns, no restocking fee on unused parts

Ships via

Quick facts

Availability	Confirmed on request
Category	Modicon Quantum
Lifecycle	Discontinued
Warranty	12-month (new) · 3-month (used/refurbished)
Country of origin	FR
UPC / EAN	3595861127104
Recommended replacement	BMXEHC0200
Datasheet	Manufacturer datasheet ↗

Shipping & availability

Can I still buy the 140EHC20200 now that it is discontinued?

Yes. Schneider Electric has discontinued the 140EHC20200, but sourcing discontinued parts is what PartnerPLC specialises in — new old stock, used and refurbished units. Request a quote and we'll confirm availability, condition and lead time. If you are planning an upgrade instead, Schneider Electric names the BMXEHC0200 as its successor — we can quote both.

When can 140EHC20200 be shipped?

140EHC20200 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up 140EHC20200 in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for 140EHC20200 and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 140EHC20200, subject to availability and destination.

Schneider Electric 140EHC20200 — Modicon Quantum - high-speed counter module - 500000 Hz. Discontinued by Schneider Electric; the manufacturer's successor is BMXEHC0200. PartnerPLC sources discontinued and surplus Schneider Electric automation parts — request a quote for price, condition and lead time.

Specifications

Main

Range of product	Modicon Quantum automation platform
Product or component type	High-speed counter module
Number of channels	2

Complementary

Addressing requirement	6 output words; 6 input words
Data format	2147483647 dec 32 bits; 65535 dec 16 bits
Counting input type	Incremental or quadrature
Counting frequency	500000 Hz
Discrete input voltage	< 30 V
Operating mode	Incremental or quadrature discrete input
Input resistance	10 kOhm discrete input
Operating threshold	0...11 V single ended mode 24 V DC at state off; 0...2 V single ended mode 5 V DC at state on; 0 V single ended mode 12 V DC at state on; 13...24 V single ended mode 24 V DC at state on; 2...7 V single ended mode 12 V DC at state off; >= 1.8 V differential mode; 3.5...5 V single ended mode 5 V DC at state off
Discrete output number	4
Discrete output type	Field Effect Transistor (FET)
Discrete output voltage	0 V switch off DC; 0.4 V switch on DC
Load current	0.5 A
Maximum leakage current	0.4 mA state off
Maximum voltage drop	<0.4 V state on
Protection type	36 V transorb for discrete output
Isolation between channels and bus	1780 Vrms for 60 s
Fault type	Loss of output field power
Output short-circuit protection	Blown fuse 2.5 A
Power dissipation	4 + (0.4 x total module load current)
Bus current requirement	650 mA
External power requirement	19.2...30 V
Rack type	Local; Remote; Distributed
Local signalling	2 LEDs for channel status
Marking	CE
Current consumption	<= 1050 mA at 24 V DC external power supply
Module format	Standard

Environment

Resistance to electrostatic discharge	4 kV contact conforming to IEC 801-2; 8 kV on air conforming to IEC 801-2
Resistance to electromagnetic fields	10 V/m 80…1000 MHz conforming to IEC 801-3
Ambient air temperature for operation	0…60 °C
Ambient air temperature for storage	-40…85 °C
Relative humidity	95 % without condensation
Operating altitude	<= 5000 m
Standards	UL 508
Product certifications	C-Tick.1; CSA No 142; FM Class 1 Division 2; UL
