Mitsubishi Electric GT15-J71GF13-T2
Mitsubishi GOT HMI Communication unit
- MPN
- GT15-J71GF13-T2
Request a Quote
- 1We check stock, condition and lead time
- 2You get a written quote by email
- 3Approve it and we ship — in-stock parts within 1 business day
- 12-month warranty (new) · 3-month (used/refurbished)
- 30-day returns, no restocking fee on unused parts
- 100% positive eBay feedback
- Ships via
Have spare Mitsubishi Electric (Factory Automation) parts? We buy surplus →
What is the Mitsubishi Electric GT15-J71GF13-T2?
The Mitsubishi Electric GT15-J71GF13-T2 is a communication unit in the GOT HMI. Intelligent device station unit. Specifications and manuals below are Mitsubishi Electric's own data.
Specifications
Product
| Series | GOT HMI |
| Outline | Intelligent device station unit |
Specifications
| Model | GT15-J71GF13-T2 |
| Category | Communication units |
| Product name | CC-Link IE Field Network communication unit |
| Series name | GOT3000/GOT2000/GOT1000 |
| CC-Link station type | Intelligent device station |
| Max. link device points per network: RWw | 8K points (8192 points, 16K bytes) |
| Max. link device points per network: RWr | 8K points (8192 points, 16K bytes) |
| Max. link device points per network: RX | 16K points (16384 points, 2K bytes) |
| Max. link device points per network: RY | 16K points (16384 points, 2K bytes) |
| Max. link device points per GOT: RWw | 1K points (1024 points, 2K bytes) |
| Max. link device points per GOT: RWr | 1K points (1024 points, 2K bytes) |
| Max. link device points per GOT: RX | 2K points (2048 points, 256 bytes) |
| Max. link device points per GOT: RY | 2K points (2048 points, 256 bytes) |
| Max. sending points per GOT: RWw | Online (Nomal mode) : 1024 points, 2K bytes Online (High-speed mode) : 256 points, 512 bytes |
| Max. sending points per GOT: RY | 2K points (2048 points, 256 bytes) |
| Communication speed | 1 Gbps |
| Connection cable | An Ethernet cable that meets the 1000BASE-T standard: Category 5e or higher (double shielded, STP), straight cable |
| Max. station-tostation distance | 100 m (conform to ANSI/TIA/EIA-568-B (category 5e)) |
| Overall cable distance | In line connection: 12000 m (when connecting 1 manager station and 120 device stations) In star connection: depends on the system configuration In ring connection: 12100 m (when connecting 1 manager station and 120 device stations) |
| Max. number of cascaded stages | 20 stages |
| Transmission path | Line type, star type (line and star mixed type is also enabled) or ring type |
| Max. number of connectable stations per network | Up to 120 stations (Control station: 1, Normal station: 119) |
| Max. number of networks | 239 |
| Communication method | Token passing method |
| Max. transient transmission capacity | 1920 bytes |
| Internal current consumption | 0.96 A |
| Weight | 0.26 kg (0.57 lb) |
| Supported model | GT37 *2 , GT27, GT2512-S, GT2510-V, GT2508-V, GT2512F-S, GT2510F-V, GT2508F-V *1 , GT1695M-X, GT1685M-S, GT1675M-S/V, GT1675-V, GT1672-V, GT1665M-S/V, GT1662-V, GT1655-V, GT15 |
| Remarks | Option units manufactured from October 2026 onward will not be covered by the warranty when used with the discontinued GOT1000 series. For the details, please refer to the Production Discontinuation of Main Units and Some Option Units in the GOT1000 Series for Overseas (GOT-A-0095) |
No matching specifications
Downloads & documentation
Official documents from Mitsubishi Electric (Factory Automation), downloaded directly from the manufacturer.
Data sheets & manuals
- GOT3000/GOT2000/GOT1000 Series CC-Link IE Field Network Communication Unit User's Manual (IB-0800473E-K)
- GOT2000 Series User's Manual (Hardware) (SH-081194ENG-AW)
- GOT2000系列 主机使用说明书(硬件篇) (SH-081202CHN-AW)
- GOT2000 Series Connection Manual (Mitsubishi Electric Products) For GT Works3 Version1 (SH-081197ENG-BA)
- GOT2000系列 连接手册(三菱电机机器连接篇) 对应GT Works3 Version1 (SH-081205CHN-BA)
- GOT2000 Series Connection Manual (Non-Mitsubishi Electric Products 1) For GT Works3 Version1 (SH-081198ENG-AU)
- GOT2000系列 连接手册(其他公司机器连接篇1) 对应GT Works3 Version1 (SH-081206CHN-AU)
- GOT2000 Series Connection Manual (Non-Mitsubishi Electric Products 2) For GT Works3 Version1 (SH-081199ENG-AQ)
- GOT2000系列 连接手册(其他公司机器连接篇2) 对应GT Works3 Version1 (SH-081207CHN-AP)
- GOT2000 Series Connection Manual (Microcomputers, MODBUS/Fieldbus Products, Peripherals) For GT Works3 Version1 (SH-081200ENG-AS)
GT15-J71GF13-T2: frequently asked questions
When can GT15-J71GF13-T2 be shipped?
GT15-J71GF13-T2 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.
Can I pick up GT15-J71GF13-T2 in person?
Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.
Is express delivery available?
Yes — mention it when you request a quote for GT15-J71GF13-T2 and we'll include express shipping options in our reply.
My factory is down and I need this urgently — can you help?
For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for GT15-J71GF13-T2, subject to availability and destination.
