Mitsubishi Electric GT15-DIOR
Mitsubishi GOT HMI Option unit
- MPN
- GT15-DIOR
Request a Quote
- 1We check stock, condition and lead time
- 2You get a written quote by email
- 3Approve it and we ship — in-stock parts within 1 business day
- 12-month warranty (new) · 3-month (used/refurbished)
- 30-day returns, no restocking fee on unused parts
- 100% positive eBay feedback
- Ships via
Have spare Mitsubishi Electric (Factory Automation) parts? We buy surplus →
What is the Mitsubishi Electric GT15-DIOR?
The Mitsubishi Electric GT15-DIOR is a option unit in the GOT HMI. For connecting an external I/O device and an operation panel (negative common input, source type output). Specifications and manuals below are Mitsubishi Electric's own data.
Specifications
Product
| Series | GOT HMI |
| Outline | For connecting an external I/O device and an operation panel (negative common input, source type output) |
Specifications
| Model | GT15-DIOR |
| Category | Option units |
| Product name | External I/O unit |
| Series name | GOT3000/GOT2000/GOT1000 |
| Common specifications: External connection method | 50-pin connector |
| Common specifications: Applicable wire size | AWG#28 or less |
| Common specifications: Operation indicator | None |
| Common specifications: External power supply *1: Voltage | 24 V DC (+20%/-15%, ripple ratio: 5% or less) |
| Common specifications: External power supply *1: Current | 1.85 A |
| Common specifications: Dielectric withstand voltage | 350 V AC per minute |
| Common specifications: Internal current consumption | 0.10 A |
| Common specifications: Weight | 0.13 kg (0.29 lb) |
| Input specifications (Sink type): Input method | Dynamic scan |
| Input specifications (Sink type): Number of input points | 16 points/128 points (16 x 8) (Output for scan: 8 points) |
| Input specifications (Sink type): Isolation method | Photocoupler |
| Input specifications (Sink type): Rated input voltage | 24 V DC (+20%/-15%, ripple ratio: 5% or less) |
| Input specifications (Sink type): Rated input current | Approx. 4 mA |
| Input specifications (Sink type): Input derating | Please refer to the following User's Manual. ・ GOT2000/GOT1000 Series External I/O Unit (Negative Common Input/ Source Output): IB-0800425 |
| Input specifications (Sink type): ON voltage/ON current *2 | 15 V DC or more/2 mA or more |
| Input specifications (Sink type): OFF voltage/OFF current *2 | 4 V DC or less/1 mA or less |
| Input specifications (Sink type): Input resistance | Approx. 5.6 KΩ |
| Input specifications (Sink type): Response time: ON to OFF | 0.4 ms or less (24 V DC) |
| Input specifications (Sink type): Response time: OFF to ON | 0.4 ms or less (24 V DC) |
| Input specifications (Sink type): Wiring method for common | 16 points per common (Common terminal: 0V (Pin No. 26 to 29)) |
| Input specifications (Sink type): Dynamic scan cycle | 13.3 ms |
| Output specifications (Source type): Output method | Direct output |
| Output specifications (Source type): Number of output points | 16 points + 1 point (RUN output *4 ) |
| Output specifications (Source type): Isolation method | Photocoupler |
| Output specifications (Source type): Rated load voltage | 24 V DC (+20%/-15%) |
| Output specifications (Source type): Max. load current | 0.1 A/1 point |
| Output specifications (Source type): Max. inrush current | 0.7 A, 10 ms or less |
| Output specifications (Source type): Leakage current at OFF | 0.1 mA or less |
| Output specifications (Source type): Max. voltage drop at ON | 0.2 V DC (Max.) 0.1 A |
| Output specifications (Source type): Protection function *5 | With overload and overheat |
| Output specifications (Source type): Response time *3: ON to OFF | 1 ms or less (Resistance load) |
| Output specifications (Source type): Response time *3: OFF to ON | 1 ms or less |
| Output specifications (Source type): Wiring method for common | 16 points per common (Common terminal: 24 V (Pin No. 1 to 4)) |
| Output specifications (Source type): Surge suppressor | Zener diode |
| Supported model | GT37 *7 , GT27, GT2512-S, GT2510-V, GT2508-V, GT2512F-S, GT2510F-V, GT2508F-V *6 , GT1695M-X, GT1685M-S, GT1675M-S/V, GT1675-V, GT1672-V, GT1665M-S/V, GT1662-V, GT1655-V, GT15 |
| Remarks | Option units manufactured from October 2026 onward will not be covered by the warranty when used with the discontinued GOT1000 series. For the details, please refer to the Production Discontinuation of Main Units and Some Option Units in the GOT1000 Series for Overseas (GOT-A-0095) |
No matching specifications
Downloads & documentation
Official documents from Mitsubishi Electric (Factory Automation), downloaded directly from the manufacturer.
Data sheets & manuals
- GOT3000/GOT2000/GOT1000 Series External I/O Unit (Negative Common Input/Source Output) User's Manual (IB-0800425E-M)
- GOT2000系列 主机使用说明书(硬件篇) (SH-081202CHN-AW)
- GOT2000 Series Connection Manual (Microcomputers, MODBUS/Fieldbus Products, Peripherals) For GT Works3 Version1 (SH-081200ENG-AS)
- GOT2000系列 连接手册(微型计算机/MODBUS/现场总线/周边机器连接篇) 对应GT Works3 Version1 (SH-081208CHN-AS)
