Mitsubishi Electric EMU4-VA2
Mitsubishi Energy measuring EcoMonitorPlus
- MPN
- EMU4-VA2
Request a Quote
- 1We check stock, condition and lead time
- 2You get a written quote by email
- 3Approve it and we ship — in-stock parts within 1 business day
- 12-month warranty (new) · 3-month (used/refurbished)
- 30-day returns, no restocking fee on unused parts
- 100% positive eBay feedback
- Ships via
Have spare Mitsubishi Electric (Factory Automation) parts? We buy surplus →
What is the Mitsubishi Electric EMU4-VA2?
The Mitsubishi Electric EMU4-VA2 is a ecoMonitorPlus in the Energy measuring. Specifications and manuals below are Mitsubishi Electric's own data.
Specifications
Product
| Series | Energy measuring |
| Category | EcoMonitorPlus |
| Type | Energy Measuring Extension Unit for Different Voltage System |
Specifications
| Category | Energy Saving Supporting Devices |
| Group | Energy Measuring Unit |
| Model | EcoMonitorPlus |
| Use | Energy Measuring Extension Unit for Different Voltage System |
| Model name | EMU4-VA2 |
| Phase wire system | Single-phase 2-wire, single-phase 3-wire, 3-phase 3-wire, 3-phase 4-wire common |
| Instrument ratings: Voltage circuit: Single-phase 2-wire 3-phase 3-wire | 110V, 220V, 440V AC common |
| Instrument ratings: Voltage circuit: Single-phase 3-wire | 110V AC (between wires 1 and 2, and wires 2 and 3), 220V AC (between wires 1 and 3) 220V AC (between wires 1 and 2, and wires 2 and 3), 440V AC (between wires 1 and 3) |
| Instrument ratings: Voltage circuit: 3-phase 4-wire | Minimum: 63.5V/110V AC, Maximum: 277V/480V AC |
| Instrument ratings: Current circuit | 50A, 100A, 250A, 400A, 600A (Dedicated split-type current sensor is used. All values indicate primary current values of current sensor.) 5A(Dedicated 5A current sensor is used. Current transformer (CT) is used in two-step configuration together with the 5A current sensor in order to allow a maximum primary current value setting of 30,000A) |
| Instrument ratings: Frequency | 50/60Hz (automatic frequency selection) |
| Auxiliary power rating | Same as measuring unit main unit (supplied from basic unit) |
| No. of measurement circuits | 2 circuits (single-phase 2-wire system: 4 circuits*) *Available for single-phase 2-wire system branced from single-phase 3-wire system. |
| Consumption VA: Voltage circuit | For each phase: 0.1VA (110V AC), 0.2VA (220V AC), 0.4VA (440V AC) |
| Consumption VA: Auxiliary power circuit | 110V AC: 1.0VA, 220VA AC:1.5VA |
| Measurement items | Current, demanded current, voltage, power, demanded power, reactive power, power factor, frequency, electric energy (regenerative, consumption), reactive electric energy, current imbalance rate, voltage imbalance rate, operating time, apparent power, harmonic current, harmonic voltage, electric energy conversion value |
| Main unit tolerances | Current, voltage, power, reactive power, apparent power, frequency: ±1.0% (relative to rated input) Power factor: ±3.0% Electric energy: ±2.0% (in 5 to 100% range of rated values; power factor = 1) Reactive electric energy: ±2.5% (in 10 to 100% range of rated values; power factor = 0) Harmonic current, harmonic voltage: ±2.5% |
| Data update cycle | 100msec |
| External output specification: Output signal format | Non-voltage a-contact 2 output (Select function from below) |
| External output specification: Pulse output specification: Output item | Electric Energy |
| External output specification: Pulse output specification: Output signal type | Non-voltage a-contact 2 output (Select function from below) |
| Weight | 0.2kg |
| External dimensions (unit: mm) | 37.5 (W) x 90 (H) x 92.9 (D) (excluding protruding parts) (Maximum size including projections: 41.5 (W) x 99 (H) x 92.9 (D)) |
No matching specifications
Downloads & documentation
Official documents from Mitsubishi Electric (Factory Automation), downloaded directly from the manufacturer.
Data sheets & manuals
- Energy Measuring Unit (EcoMonitorPlus), Small Type Display Unit for Energy Measuring Unit, Through type zero-phase current transformer, Split type zero-phase current transformer Before using the instr
- Energy Measuring Unit (EcoMonitorPlus) Extension for the system with the same voltage / Extension for the system with the different voltage User's Manual (Digest) (MODEL:EMU4-A2/EMU4-VA2) (IB63A19E-E)
- Energy Measuring Unit (EcoMonitorPlus) Energy Measuring Extension Model for Same Voltage System / Energy Measuring Extension Model for Different Voltage System User's Manual (Details) (MODEL:EMU4-A2/E
- Energy Measuring Unit Programming Manual (CC-Link) For ver.1 remote device station (EcoMonitorPro/EMU3/EcoMonitorLight/EcoMonitorPlus Series) (LEN160305-C)
- Energy Measuring Unit Programming Manual (CC-Link) For ver.2 remote device station (MODEL:EMU4-BD1-MB/EMU4-HD1-MB/EMU4-BM1-MB/EMU4-HM1-MB/EMU4-LG1-MB/EMU4-A2/EMU4-VA2/EMU4-AX4/EMU4-PX4) (LEN160316-C)
- Energy Measuring Unit Programming Manual (CC-Link IE Field Network Basic) (SLMP) (MODEL:EMU4-BD1-MB/EMU4-HD1-MB/EMU4-FD1-MB/EMU4-BM1-MB/EMU4-HM1-MB/EMU4-LG1-MB/EMU4-A2/EMU4-VA2/EMU4-AX4/EMU4-PX4) (LEN
- Energy Measuring Unit Programming Manual (CC-Link IE TSN) (SLMP) (MODEL:EMU4-BD1A-MB/EMU4-HD1A-MB/EMU4-FD1-MB/EMU4-BM1-MB/EMU4-HM1-MB/EMU4-LG1-MB/EMU4-CNT-MB/EMU4-A2/EMU4-VA2/EMU4-AX4/EMU4-PX4) (LEN21
- Energy Measuring Unit EcoMonitorLight/EcoMonitorPlus Series MODBUS I/F Specification (MODEL:EMU4-BD1-MB/EMU4-HD1-MB/EMU4-BM1-MB/EMU4-HM1-MB/EMU4-LG1-MB/EMU4-CNT-MB/EMU4-A2/EMU4-VA2/EMU4-PX4/EMU4-AX4)
