What is the Mitsubishi Electric EMU4-AX4?
The Mitsubishi Electric EMU4-AX4 is a ecoMonitorPlus in the Energy measuring. Specifications and manuals below are Mitsubishi Electric's own data.
Specifications
Product
| Series | Energy measuring |
| Category | EcoMonitorPlus |
| Type | Analog Input Unit |
Specifications
| Category | Energy Saving Supporting Devices |
| Group | Energy Measuring Unit |
| Model | EcoMonitorPlus |
| Use | Analog Input Unit |
| Model name | EMU4-AX4 |
| Input specifications: Number of input contacts | 4 points |
| Input specifications: Input signal format | Differential input (0 to +5V, 0 to +20mA) |
| Input specifications: Rated input voltage/current | Voltage: 0 to +5V (Input resistance: 1MΩ) Current: 0 to +20mA (Input resistance: 250Ω) * Input range (voltage/current) can be switched. (Switch each channel in the settings.) |
| Input specifications: Measured items | AD conversion value, scaling value, number of times level exceeded |
| Input specifications: Range of measurement values | AD conversion value: 0 to 4095 Scaling value: -32,767 to 32,767 |
| Input specifications: Accuracy | AD conversion value: Input rating ±1.0% (23℃±10℃) |
| Input specifications: Data update cycle | 1 ms x number of channels 50 ms x number of channels |
| External output: Output signal type | Non-voltage a-contact, 1 output |
| External output: Functions: Alarm elements | Scaling value upper/lower limit monitoring, scaling value upper limit monitoring, scaling value lower limit monitoring |
| Compatible standard | CE marking (EMC: EN-61326-1: 2013, Safety: EN-61010-1: 2010), UL: UL61010-1 |
| Consumption VA: Single unit | 110V AC: 2.0VA, 220V AC: 2.5VA |
| Weight | 0.2kg |
| External dimensions (unit: mm) | 37.5 (W) x 90 (H) x 92.9 (D) (excluding protruding parts) (Maximum size including projections: 41.5 (W) x 99 (H) x 92.9 (D)) |
No matching specifications
Downloads & documentation
Official documents from Mitsubishi Electric (Factory Automation), downloaded directly from the manufacturer.
Data sheets & manuals
- Energy Measuring Unit (EcoMonitorPlus), Small Type Display Unit for Energy Measuring Unit, Through type zero-phase current transformer, Split type zero-phase current transformer Before using the instr
- Energy Measuring Unit (EcoMonitorPlus) Extension for Pulse Input / Extension for Analog Input User's Manual (Digest) (MODEL:EMU4-PX4/EMU4-AX4) (IB63C96E-F)
- Energy Measuring Unit (EcoMonitorPlus) Extension Model for Pulse Input / Extension Model for Analog Input User's Manual (Details) (MODEL:EMU4-PX4/EMU4-AX4) (IB63D01-G)
- Energy Measuring Unit Programming Manual (CC-Link) For ver.1 remote device station (EcoMonitorPro/EMU3/EcoMonitorLight/EcoMonitorPlus Series) (LEN160305-C)
- Energy Measuring Unit Programming Manual (CC-Link) For ver.2 remote device station (MODEL:EMU4-BD1-MB/EMU4-HD1-MB/EMU4-BM1-MB/EMU4-HM1-MB/EMU4-LG1-MB/EMU4-A2/EMU4-VA2/EMU4-AX4/EMU4-PX4) (LEN160316-C)
- Energy Measuring Unit Programming Manual (CC-Link IE Field Network Basic) (SLMP) (MODEL:EMU4-BD1-MB/EMU4-HD1-MB/EMU4-FD1-MB/EMU4-BM1-MB/EMU4-HM1-MB/EMU4-LG1-MB/EMU4-A2/EMU4-VA2/EMU4-AX4/EMU4-PX4) (LEN
- Energy Measuring Unit Programming Manual (CC-Link IE TSN) (SLMP) (MODEL:EMU4-BD1A-MB/EMU4-HD1A-MB/EMU4-FD1-MB/EMU4-BM1-MB/EMU4-HM1-MB/EMU4-LG1-MB/EMU4-CNT-MB/EMU4-A2/EMU4-VA2/EMU4-AX4/EMU4-PX4) (LEN21
- Energy Measuring Unit EcoMonitorLight/EcoMonitorPlus Series MODBUS I/F Specification (MODEL:EMU4-BD1-MB/EMU4-HD1-MB/EMU4-BM1-MB/EMU4-HM1-MB/EMU4-LG1-MB/EMU4-CNT-MB/EMU4-A2/EMU4-VA2/EMU4-PX4/EMU4-AX4)
