What is the Mitsubishi Electric BHW-T10?

The Mitsubishi Electric BHW-T10 is a circuit Breaker in the Circuit breaker. IEC CE(LVD) CE(RoHS) UKCA(LV) UKCA(RoHS). Specifications and manuals below are Mitsubishi Electric's own data.

Specifications

Product

SeriesCircuit breaker
OutlineIEC CE(LVD) CE(RoHS) UKCA(LV) UKCA(RoHS)

Specifications

DescriptionMCB
SeriesDIN series
TypeBHW-T10
Number of poles1
Tripping characteristicsType B
Rated insulation voltage Ui (V)660
Rated current In (A) at30℃6,10,16,20,25,32,40,50,63
Rated short-circuit capacity Icn (kA): IEC/EN 60898-1 GB/T 10963.1: 400VAC-
Rated short-circuit capacity Icn (kA): IEC/EN 60898-1 GB/T 10963.1: 230/400VAC-
Rated short-circuit capacity Icn (kA): IEC/EN 60898-1 GB/T 10963.1: 230VAC-
Rated short-circuit capacity Icn (kA): IEC/EN 60898-2 GB/T 10963.2: 250VDC-
Rated short-circuit capacity Icn (kA): IEC/EN 60898-2 GB/T 10963.2: 125VDC-
Rated short-circuit capacity Icn (kA): IEC/EN 60898-2 GB/T 10963.2: 400VAC-
Rated short-circuit capacity Icn (kA): IEC/EN 60898-2 GB/T 10963.2: 230/400VAC-
Rated short-circuit capacity Icn (kA): IEC/EN 60898-1: 415VAC-
Rated short-circuit capacity Icn (kA): IEC/EN 60898-1: 240/415VAC10
Rated short-circuit capacity Icn (kA): IEC/EN 60898-1: 240VAC10
Rated short-circuit capacity Icn (kA): IEC/EN 60898-1: 240/415VAC-
Rated short-circuit breaking capacity Icu/Ics (kA): IEC/EN 60947-2: 240/415VAC-
Rated impulse withstand voltage Uimp (kV)4
Energy limiting classclass 3
Isolation●
Utilization category-
Pollution degree2
Number of operation cycles (times): Without current4000
Number of operation cycles (times): With current4000
Outline dimensions (mm): a18
Outline dimensions (mm): b92.6
Outline dimensions (mm): c44
Outline dimensions (mm): caMAX 73.5
Overload relay typeThermal-magnetic
MountingIEC35mm rail
Applicable wire size1-25mm2
Mass (kg)0.13
Accessories: Alarm switch(AL)-
Accessories: Auxiliary switch (AX)-
Accessories: Shunt trip device (SHT)-
Accessories: Handle Lock (HL)-
Terminal connectionSolderless
Standard: Based onIEC 60898-1, EN 60898-1
Standard: CE markingSelf-declaration
Standard: UKCA markingSelf-declaration
Standard: CCC-
Standard: Marine use approval-
Standard: Third party approval: KEMACertified
