BVW-T Mitsubishi Circuit breaker 2(1+N)

MPN: BVW-T · Brand: Mitsubishi Electric (Factory Automation)

Price on request

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)

30-day returns, no restocking fee on unused parts

Ships via

Quick facts

Availability	Confirmed on request
Category	Mitsubishi Circuit breaker – Circuit Breakers
Lifecycle	Active
Warranty	12-month (new) · 3-month (used/refurbished)

Shipping & availability

When can BVW-T be shipped?

BVW-T is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up BVW-T in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for BVW-T and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for BVW-T, subject to availability and destination.

The Mitsubishi Electric BVW-T is a 2(1+N) in the Circuit breaker. IEC CE(EMC) CE(LVD) CE(RoHS) UKCA(EMC) UKCA(LV) UKCA(RoHS). Specifications and manuals below are Mitsubishi Electric's own data.

Specifications

Product

Series	Circuit breaker
Category	2(1+N)
Outline	IEC CE(EMC) CE(LVD) CE(RoHS) UKCA(EMC) UKCA(LV) UKCA(RoHS)

Specifications

Description	RCCB
Series	DIN series
Type	BVW-T
Number of poles	2(1+N)
Rated current In(A) at30℃	16,25,32,40,63
Rated voltage (VAC)	240
Rated current sensitivity I△n (mA)	30,100,300
Max. operating time at 5I△n (s)	0.04
Leakage detection characteristics	Type AC
Rated conditional short-circuit current Inc (kA)	10
Rated short-circuit capacity Icn(kA): IEC 61009	－
Tripping characteristics	－
Outline dimensions (mm): a	36
Outline dimensions (mm): b	90
Outline dimensions (mm): c	44
Outline dimensions (mm): ca	74
Mass (kg)	0.22
Rated making and breaking capacity Im (A)	500（In 16,25,32,40A) 630（In 63A)
Rated residual making and breaking capacity I△m (A)	500（In 16,25,32,40A) 630（In 63A)
Rated conditional residual short-circuit current I△c (kA)	10
Number of operating cycles (times): Without current	4000（In 16,25A）, 3000（In 32,40,63A）
Number of operating cycles (times): With current	2000
Type of overcurrent release	－
Mounting	IEC35mm rail
Applicable wire size	1-25ｍｍ2
Terminal connection	Solderless
Standard: Based on	IEC 61008-1, EN 61008-1
Standard: CE marking	Self-declaration
Standard: UKCA marking	Self-declaration
Standard: CCC	－
Standard: Third party approval: KEMA	Certified
