What is the Mitsubishi Electric BV-DN?

The Mitsubishi Electric BV-DN is a 2(1+N) in the Circuit breaker. IEC CE(EMC) CE(LVD) CE(RoHS) UKCA(EMC) UKCA(LV) UKCA(RoHS) CCC. Specifications and manuals below are Mitsubishi Electric's own data.

Specifications

Product

SeriesCircuit breaker
Category2(1+N)
OutlineIEC CE(EMC) CE(LVD) CE(RoHS) UKCA(EMC) UKCA(LV) UKCA(RoHS) CCC

Specifications

DescriptionRCBO
SeriesDIN series
TypeBV-DN
Number of poles2(1+N)
Rated current In(A) at30℃6,10,16,20,25,32,40
Rated voltage (VAC)230
Rated current sensitivity I△n (mA)30,100,300
Max. operating time at 5I△n (s)0.04
Leakage detection characteristicsType AC
Rated conditional short-circuit current Inc (kA)-
Rated short-circuit capacity Icn(kA): IEC 610094.5
Tripping characteristicsType C
Outline dimensions (mm): a36
Outline dimensions (mm): b88
Outline dimensions (mm): c44
Outline dimensions (mm): ca70
Mass (kg)0.19
Rated making and breaking capacity Im (A)-
Rated residual making and breaking capacity I△m (A)500
Rated conditional residual short-circuit current I△c (kA)-
Number of operating cycles (times): Without current20000
Number of operating cycles (times): With current20000(In6,10,16,20A),15000(In25A), 10000(In32,40A)
Type of overcurrent releaseThermal-magnetic
MountingIEC35mm rail
Applicable wire size1-16mm2
Terminal connectionSolderless
Standard: Based onIEC 61009-1, IEC 61009-2-2, EN 61009-1, GB/T 16917.1, GB/T 16917.22
Standard: CE markingSelf-declaration
Standard: UKCA markingSelf-declaration
Standard: CCCCertified
Standard: Third party approval: KEMA-
