BH-DN Mitsubishi Circuit breaker 2(1+Ｎ)

MPN: BH-DN · Brand: Mitsubishi Electric (Factory Automation)

Price on request

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)

30-day returns, no restocking fee on unused parts

Ships via

Quick facts

Availability	Confirmed on request
Category	Mitsubishi Circuit breaker – Circuit Breakers
Lifecycle	Active
Warranty	12-month (new) · 3-month (used/refurbished)

Shipping & availability

When can BH-DN be shipped?

BH-DN is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up BH-DN in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for BH-DN and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for BH-DN, subject to availability and destination.

The Mitsubishi Electric BH-DN is a 2(1+Ｎ) in the Circuit breaker. IEC CE(LVD) CE(RoHS) UKCA(LV) UKCA(RoHS) CCC. Specifications and manuals below are Mitsubishi Electric's own data.

Specifications

Product

Series	Circuit breaker
Category	2(1+Ｎ)
Outline	IEC CE(LVD) CE(RoHS) UKCA(LV) UKCA(RoHS) CCC

Specifications

Description	MCB
Series	DIN series
Type	BH-DN
Number of poles	2(1+Ｎ)
Tripping characteristics	Type Ｃ
Rated insulation voltage Ui (V)	230
Rated current In (A) at30℃	6,10,16,20
Rated short-circuit capacity Icn (kA): IEC/EN 60898-1 GB/T 10963.1: 400VAC	－
Rated short-circuit capacity Icn (kA): IEC/EN 60898-1 GB/T 10963.1: 230/400VAC	－
Rated short-circuit capacity Icn (kA): IEC/EN 60898-1 GB/T 10963.1: 230VAC	4.5
Rated short-circuit capacity Icn (kA): IEC/EN 60898-2 GB/T 10963.2: 250VDC	－
Rated short-circuit capacity Icn (kA): IEC/EN 60898-2 GB/T 10963.2: 125VDC	－
Rated short-circuit capacity Icn (kA): IEC/EN 60898-2 GB/T 10963.2: 400VAC	－
Rated short-circuit capacity Icn (kA): IEC/EN 60898-2 GB/T 10963.2: 230/400VAC	－
Rated short-circuit capacity Icn (kA): IEC/EN 60898-1: 415VAC	－
Rated short-circuit capacity Icn (kA): IEC/EN 60898-1: 240/415VAC	－
Rated short-circuit capacity Icn (kA): IEC/EN 60898-1: 240VAC	－
Rated short-circuit capacity Icn (kA): IEC/EN 60898-1: 240/415VAC	－
Rated short-circuit breaking capacity Icu/Ics (kA): IEC/EN 60947-2: 240/415VAC	－
Rated impulse withstand voltage Uimp (kV)	4
Energy limiting class	－
Isolation	●
Utilization category	－
Pollution degree	2
Number of operation cycles (times): Without current	20000
Number of operation cycles (times): With current	20000
Outline dimensions (mm): a	18
Outline dimensions (mm): b	88
Outline dimensions (mm): c	44
Outline dimensions (mm): ca	70
Overload relay type	Thermal-magnetic
Mounting	IEC35mm rail
Applicable wire size	1-10ｍｍ2
Mass (kg)	0.12
Accessories: Alarm switch（AL）	－
Accessories: Auxiliary switch (AX)	－
Accessories: Shunt trip device (SHT)	－
Accessories: Handle Lock (HL)	●
Terminal connection	Solderless
Standard: Based on	IEC 60898-1, EN 60898-1, GB/T 10963.1
Standard: CE marking	Self-declaration
Standard: UKCA marking	Self-declaration
Standard: CCC	Certified
Standard: Marine use approval	－
Standard: Third party approval: KEMA	－
