BZ-110C Mitsubishi Power monitoring Zero-phase Current Transformers (ZCT)
Request a Quote
Quick facts
| Availability | Confirmed on request |
| Category | Mitsubishi Power monitoring – Instrument Transformers |
| Lifecycle | Active |
| Warranty | 12-month (new) · 3-month (used/refurbished) |
Shipping & availability
When can BZ-110C be shipped?
BZ-110C is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.
Can I pick up BZ-110C in person?
Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.
Is express delivery available?
Yes — mention it when you request a quote for BZ-110C and we'll include express shipping options in our reply.
My factory is down and I need this urgently — can you help?
For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for BZ-110C, subject to availability and destination.
The Mitsubishi Electric BZ-110C is a zero-phase Current Transformers (ZCT) in the Power monitoring. Specifications and manuals below are Mitsubishi Electric's own data.
Specifications
Product
| Series | Power monitoring |
| Category | Zero-phase Current Transformers (ZCT) |
| Type | By cable insulation |
| Subtype | 10Ω |
Specifications
| Category | Instrument Transformers |
| Group | Zero-phase Current Transformers (ZCT) |
| Circuit voltage | By cable insulation |
| Use | Grounding relays・Through-type |
| Model name | BZ-110C |
| Window diameter (φmm) | 110 |
| Rated primary current (A) | 1000 |
| Rated zero-phase primary current | 200mA |
| Rated zero-phase secondary current | 1.5mA |
| Rated burden | 10Ω |
| Frequency (Hz) | Both 50/60 |
| Applicable standards | JEC-1201-2007 |
| Accuracy (class) | L |
| Mass (kg) | 10 |
