Mitsubishi Electric BH-D10

Mitsubishi Circuit breaker

MPN
BH-D10
Price and lead time confirmed within 1 business day
Request a Quote
  1. 1We check stock, condition and lead time
  2. 2You get a written quote by email
  3. 3Approve it and we ship — in-stock parts within 1 business day

A real person replies, typically within 1 business day — see our privacy policy.

  • 12-month warranty (new) · 3-month (used/refurbished)
  • 30-day returns, no restocking fee on unused parts
  • 100% positive eBay feedback
  • Ships via

Have spare Mitsubishi Electric (Factory Automation) parts? We buy surplus →

What is the Mitsubishi Electric BH-D10?

The Mitsubishi Electric BH-D10 is a circuit Breaker in the Circuit breaker. IEC CE(LVD) CE(RoHS) UKCA(LV) UKCA(RoHS) CCC DNV CCS. Specifications and manuals below are Mitsubishi Electric's own data.

Specifications

Product

SeriesCircuit breaker
OutlineIEC CE(LVD) CE(RoHS) UKCA(LV) UKCA(RoHS) CCC DNV CCS

Specifications

DescriptionMCB
SeriesDIN series
TypeBH-D10
Number of poles1
Tripping characteristicsType B,C,D
Rated insulation voltage Ui (V)440
Rated current In (A) at30℃0.5,1,1.6,2,3,4,6,10,13,16,20,25,32,40,50,63
Rated short-circuit capacity Icn (kA): IEC/EN 60898-1 GB/T 10963.1: 400VAC-
Rated short-circuit capacity Icn (kA): IEC/EN 60898-1 GB/T 10963.1: 230/400VAC10
Rated short-circuit capacity Icn (kA): IEC/EN 60898-1 GB/T 10963.1: 230VAC10
Rated short-circuit capacity Icn (kA): IEC/EN 60898-2 GB/T 10963.2: 250VDC-
Rated short-circuit capacity Icn (kA): IEC/EN 60898-2 GB/T 10963.2: 125VDC-
Rated short-circuit capacity Icn (kA): IEC/EN 60898-2 GB/T 10963.2: 400VAC-
Rated short-circuit capacity Icn (kA): IEC/EN 60898-2 GB/T 10963.2: 230/400VAC-
Rated short-circuit capacity Icn (kA): IEC/EN 60898-1: 415VAC-
Rated short-circuit capacity Icn (kA): IEC/EN 60898-1: 240/415VAC-
Rated short-circuit capacity Icn (kA): IEC/EN 60898-1: 240VAC-
Rated short-circuit capacity Icn (kA): IEC/EN 60898-1: 240/415VAC-
Rated short-circuit breaking capacity Icu/Ics (kA): IEC/EN 60947-2: 240/415VAC-
Rated impulse withstand voltage Uimp (kV)4
Energy limiting class-
Isolation●
Utilization category-
Pollution degree2
Number of operation cycles (times): Without current10000
Number of operation cycles (times): With current10000
Outline dimensions (mm): a18
Outline dimensions (mm): b87
Outline dimensions (mm): c44
Outline dimensions (mm): ca70
Overload relay typeThermal-magnetic
MountingIEC35mm rail
Applicable wire size1-25mm2
Mass (kg)0.15
Accessories: Alarm switch(AL)●
Accessories: Auxiliary switch (AX)●
Accessories: Shunt trip device (SHT)●
Accessories: Handle Lock (HL)●
Terminal connectionSolderless
Standard: Based onIEC 60898-1, EN 60898-1, GB/T 10963.1
Standard: CE markingSelf-declaration
Standard: UKCA markingSelf-declaration
Standard: CCCCertified
Standard: Marine use approvalCCS, DNV
Standard: Third party approval: KEMA-

BH-D10: frequently asked questions

When can BH-D10 be shipped?

BH-D10 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up BH-D10 in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for BH-D10 and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for BH-D10, subject to availability and destination.
